Guida al cablaggio

Svariati sono i modi di interfacciare il subwoofer Resolv RXA a seconda dell'esatta
configurazione del monitoraggio. Per collegare il sistema di diffusione fare riferimen-
to ai diagrammi di cablaggio riportati di seguito.
RCA
Pin 2 (hot)
Pin 3 (cold)
Pin 1 (shield)
Tip (+Signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Unbalanced ¼" Connector
Pin 2 (hot)
Pin 1 (shield)
Pin 3 (cold)
Balanced ¼" Connector
Pin 2 (hot)
Pin 1 (shield)
Pin 3 (cold)
50
Male XLR
Ring (-Signal)
Balanced ¼" Connector
Unbalanced ¼" Connector
Male XLR
Male XLR
Shield & Cold to Sleeve
Tip to Tip
Sleeve & Ring to Sleeve
Tip to Tip
Sleeve to Sleeve
Hot to Tip
Shield & Cold to Sleeve
Hot to Tip
Shield & Cold to Sleeve
Hot to Tip
Tip (signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Ring (-Signal)
Tip (signal)
Sleeve (ground)
Tip (signal)
Sleeve (ground)
Tip (+Signal)
Sleeve (ground)
