Sound: On / Off; Menu Operation - Comelit RS485 Mode D'emploi


LANGUAGE: ENGLISH


SOUND: ON / OFF


ADDRESS: 000 ～ 255

BAUD RATE: 1200 / 2400 / 4800 / 9600 / 19200 BPS

3.5 Menu Operation

When joystick and keys are operated at the same time, joystick operation
is preferred.
Rotating the joystick to any direction can exit the present setting page
(except on menu page).
When setting parameters in menu, pressing [Enter] can make the setting
effective. The key [Enter] just store the latest changed parameters of menu.
For example, if you change protocol, address and baud rate in order, then
press [Enter], only baud rate is changed successfully.
When there is nothing in the second line on LCD as Fig 3.5.1, number
keys [2], [8], [4], [6] can be used as up, down, left and right keys to control
PTZ or dome camera left and right rotation as the function of joystick, but the
rotation speed is the fastest and no grades to select, shown as 3.5.2 (e.g key
[2]).
PELCO-D 2400 000
Fig 3.5.1
After entering menu, joystick has no function to control PTZ or dome
camera. It can only be used as up or down to flip the menu page and left or
right to change the parameters of menu. Number keys [0], [1], [3], [5], [7], [9]
are invalid. [2], [8], [4], [6] are used as up, down, left and right keys. They are
not used as number keys at this time. Their functions are just to flip the menu
page but not to control PTZ or dome camera's up, down, left or right rotation.
Only after exiting menu and when there is nothing in the second line on LCD,
they can control dome camera's up, down, left and right rotation.
When setting [ADDRESS], number keys [0], [1], [3], [5], [7], [9] restore
the number keys' function. [2], [8], [4], [6] restore the number keys' function
and don't have up, down, left and right functions.
When pressing [Enter] after address setting on menu finishes, it will enter
PELCO-D 2400 000
PT->UP
Fig 3.5.2
