Technical Data

Torque
Free speed
Min
Model
1
2
[min-1]
[Nm]
max. pressure 6.3bar(90psi)
a
: Vibration level, k Uncertainty ; L
h
Declaration of noise and vibration statement (ISO 15744 and ISO 28927-2)
All values are current as of the date of this publication. For the latest information please visit www.rodcraft.com.
These declared values were obtained by laboratory type testing in accordance with the stated standards and are suitable for comparison with the declared values of other tools
tested in accordance with the same standards. These declared values are not adequate for use in risk assessments and values measured in individual work places may be
higher. The actual exposure values and risk of harm experienced by an individual user are unique and depend upon the way the user works, the workpiece and the workstation
design, as well upon the exposure time and the physical condition of the user. We, RODCRAFT PNEUMATIC TOOLS , cannot be held liable for the consequences of using the
declared values, instead of values reflecting the actual exposure, in an individual risk assessment in a work place situation over which we have no control. This tool may cause
hand-arm vibration syndrome if its use is not adequately managed. An EU guide to managing hand-arm vibration can be found at www. pneurop.eu/uploads/documents/pdf/
PN3-02-NV_Declaration_info_sheet_0111.pdf. We recommend a programme of health surveillance to detect early symptoms which may relate to noise or vibration exposure,
so that management procedures can be modified to help prevent future impairment.
Additional Vibration Information
This tool may cause hand-arm vibration syndrome if its use is not adequately managed.
This additional vibration information may be of assistance to employers in meeting theirobligations (for example under EU Directive 2002/44/EC) to assess the risks to their
workers arising from hand arm vibration associated with the use of this tool.
Slip clutch screwdrivers are suitable for wood or self-tapping or self-drilling applications where torque requirements are not consistent.
• The declared vibration value can be used to estimate vibration during rundown. When slipping, the clutch may produce a considerably higher vibration emission which varies
with torque setting.
Model
RC4784
• Only use this tool for work which other types of screwdrivers, which present lower vibration risks, are unable to perform satisfactorily.
• The vibration emission varies greatly with task and operator technique. Emissions outside the quoted range may occur for some applications.
• Operators should optimize their technique in order to minimize the clutch slipping time for each fastening operation.
• For the intended application of this tool, we estimate that normal operation should involve a clutch slipping time of less than 0,5s per fastener.
We point out that application of the tool to a sole specialist task may produce a different average emission and in such cases we strongly recommend a specific evaluation of the vibration
emission.
Machine type(s)
• This product is designed for installing and removing threaded fasteners in wood, metal and plastic.No other use permitted. For professional use only.
• Please read the instructions carefully before starting the machine.
Operation (See figures)
• Fix the accessories properly to the tool.
• Connect device as shown in Fig. 01.
• To start the machine, pull the trigger (A). Machine speed is increase by increasing pressure on the trigger. Release the trigger to stop.
• To switch rotation, push the switch (B) as shown in Fig. 03
Lubrication
• Use an air line lubricator with SAE #10 oil, adjusted to two drops per minute. If an air line lubricator cannot be used, add air motor oil to the inlet once a day.
Maintenance instruction
• Follow local country environmental regulations for safe handling and disposal of all components.
• Maintenance and repair work must be carried out by qualified personnel using only original spare parts. Contact the manufacturer or your nearest authorised dealer for advice
on technical service or if you require spare parts.
• Always ensure that the machine is disconnected from energy source to avoid accidental operation.
• Disassemble and inspect the tool every three 3 months if the tool is used every day. Replace damaged or worn parts.
• To keep downtime to a minimum, the following service kits are recommended :
Tune-Up Kit : see part list
Disposal
• The disposal of this equipment must follow the legislation of the respective country.
• All damaged, badly worn or improperly functioning devices MUST BE TAKEN OUT OF OPERATION.
• Repair only by technical maintenance staff.
EU Declaration of Conformity
We : Rodcraft Customer Center Langemarckstr.35 bis 45141 Essen- Germany
Machine type(s):
Screwdriver
Declare under our sole responsibility that the product(s): RC4784
Origin of the product : TAIWAN
is in conformity with the requirements of the council Directives on the approximation of the laws of the Member States relating : to "Machinery"
applicable harmonised standard(s) :
Name and position of issuer :
Pascal Roussy (R&D Manager)
Place & Date :
Saint-Herblain, 09/2016
Technical file available from EU headquarter. Pascal Roussy, R&D manager CP Technocenter 38, rue Bobby Sands - BP10273 44800 Saint Herblain - France
Copyright 2016, Rodcraft
All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings.
Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability.
Dimension
Weight
LxHxW
Max
H
W
L
3
4
5
[kg]
[Nm]
[mm]
Sound pressure dB(A), K
= K
pA
pA
Typical vibration emission when ratcheting at max. torque setting (vibration total values, m/s2)
Serial Number: 001-999
EN ISO 11148-6:2012
Air Consumption
Air Inlet
Free speed
6
7
[l/min]
[inch]
= 3 dB Uncertainty.
WA
Original Instructions
Screwdriver
Sound pressure
Inner Hose
Sound power
Dia.
L
pA
8
9
[mm]
[dB(A)]
[dB(A)]
X
2006/42/EC (17/05/2006)
RC4784
Vibrations
L
a
K
wA
h
10
11
[m/s²]
[m/s²]
