G Operating Instructions
1080p HD Capture Box
Item no. 494317
Intended use
The product is intended to be connected to a USB-port of a computer for digitalising
an analogue or digital AV-signal.
This product complies with the applicable national and European requirements. All
names of companies and products are the trademarks of the respective owners. All
rights reserved.
HDMI is a registered trademark of HDMI Licensing L.L.C.
Contents
• HD capture box
• Cable set
• CD with driver, software and manufacturer's instructions (in English)
• Quick guide
Safety Instructions
T he warranty will be void in the event of damage caused by failure to ob-
serve these safety instructions! We do not assume any liability for any re-
sulting damage!
W e shall not accept liability for damage to property or personal injury
caused by incorrect handling or non-compliance with the safety instruc-
tions! In such cases, the warranty will be null and void.
• The unauthorised conversion and/or modification of the product is not permitted for
safety and approval reasons (CE). Do not open/disassemble!
• The product is not a toy and should be kept out of the reach of children.
• The product must not become damp or wet.
• Do not leave packaging material carelessly lying around, as it could become a dan-
gerous plaything for children.
• Handle the product with care; it can be damaged by impacts, blows, or accidental
falls, even from a low height.
Driver/Software Installation
• Boot your operating system (Windows XP or higher) and wait until the boot has
finished.
• Connect the HD capture box via the USB cable provided to a free USB2.0 port of
your computer. Windows then recognises the new hardware; cancel the hardware
detection.
• Insert the enclosed CD into an appropriate drive on your computer. If the installation
software does not start automatically, you must start it manually.
• After the installation of driver and software completes, restart the computer.
Connection
Depending on the available devices whose AV signal you want to digitise, the corres-
ponding cable connection is to be made.
Note the labels on the HD capture box; inputs ("IN") and outputs ("OUT") are available
for each of the following:
• Stereo audio signal
• SVideo signal
• Component video signal
• HDMI AV signal
The respective signal fed in at the input is transmitted to the corresponding
output. The HD capture box can thus be looped into a signal connection in
order to record it.
Tips and Notes
• It is necessary to use a USB2.0 port to prevent interruptions and juddering during
the video recording.
• Connect the HD capture box only to a USB port capable of delivering a current of
500 mA (e.g., a USB port of the computer or of a USB hub with separate power
supply).
• Restart your computer after driver installation, since otherwise the HD capture box
will not be recognised properly by Windows.
• The recording of a copy-protected HDMI signal is not possible.
• When connecting a component signal, make sure that the 3 cable connections are
not confused.
• Pay attention to the comprehensive (English) operating instructions on the provided
CD.
To view the PDF file, you need a PDF viewer such as "Acrobat Reader", which you can
download free of charge at www.adobe.com.
Disposal
Dispose of an unserviceable product in accordance with the relevant statu-
tory regulations.
Technical Data
Connection .................................................. USB2.0
Power supply .............................................. 5 V/DC, max. 500 mA, via USB
Operating system requirement ................ Windows XP or above
Inputs/Outputs ............................................ Stereo audio signal (cinch sockets)
.......................................................................
.......................................................................
.......................................................................
Dimensions.................................................. 139 x 90 x 27.5 mm (W x D x H)
Weight .......................................................... 150 g
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in technology and equipment reserved.
© Copyright 2014 by Conrad Electronic SE.
SVideo (S-Video jack)
Component video signal (cinch sockets)
HDMI AV signal (HDMI jacks)
