12 Device information

1 Type and order code
2 Design
Heat source
2.1 Model
2.2 Controller
2.3 Installation location Haed pump / Hydro tower
2.4 Thermal energy metering
2.5 Performance levels
3 Operating limits
3.1 Heating water flow / return
1
3.2 Air (heating)
2
4 Flow / sound
4.1 Heating water flow free compression
Nominal flow in accordance with EN 14511
at A7 / W35...30
at A7 / W45...40
at A7 / W55...47
4.2 Minimum heating water flow rate
Heat pump circuit
4.3 Sound power level according to EN 12102
Normal operation / reduced operation
4.4 Sound pressure level at a distance of 10 m (air outlet side)
Normal operation / reduced operation
4.5 Air flow
Normal operation / reduce operation
5 Dimensions, weight and filling quantities
5.1 Device dimensions without connectionsH x W x L mm
5.2 Device connections for heating
5.3 Weight of the transportable unit(s) incl. packagingkg
5.4 Refrigerant / total filling weight
5.5 GWP value / CO equivalent
2
5.6 Refrigeration circuit hermetically sealed
5.7 Lubricant / total filling quantity
5.8 Volume of heating water in device
6 Electrical connection
6.1 Supply voltage / fusing / RCD type
6.2 Control voltage / fusing by WPM
6.3 Degree of protection according to EN 60529
6.4 Starting current limiter
6.5 Rotary field monitoring
6.6 Starting current with soft starter
6.7 Nominal power consumption A2/W35 /
max. power consumption
Nominal current A2 /W35 / cos 
6.8
6.9 Power consumption of compressor protection
(per compressor)
6.10 Power consumption of fan
EN-10
1
°C
°C
m³/h / Pa
m³/h / Pa
m³/h / Pa
m³/h
4 5
dB(A)
4 5
dB(A)
5
m³/h
inches
type/kg
--- / t
type/litres
Litres
A
2
kW
A / ---
W / ---
W
452168.66.11 · FD 9912
6
HPL 9S-TUW2
HPL 9S-TUW2
Air
Universal with hydro tower
Integrated (hydro tower)
Outdoors / Indoors
Integrated
1
up to 60 ± 2 / from 18
-22 to +35
1.5 / 41500
1.4 / 44600
3
0.9 / 61900
1.2
53 / 53
25 / 25
2700 / 2100
1650 x 910 x 750
G 1 1/4" external thread
225
R410A / 3.9
2088 / 8
yes
Polyolester (POE) / 1.2
2.6
3~/N/PE 400 V (50 Hz) / C10 A / A
1~/N/PE 230 V (50 Hz) / 4 AT
IP 24
Soft starter
Yes
21
1.8 / 3.3
3.1 / 0.8
70 / thermostatically controlled
up to 100
