Operating Instructions
USB-Webcam Classic (BS-WC-01)
Item No. 1616189
Intended Use
This plug and play USB device has a built-in microphone and a lens focus ring for adjusting
image sharpness. The swivel joint combined with a versatile desktop stand / laptop mounting
system allows you to optimize your camera angle for recording.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in
bathrooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use
the product for purposes other than those described above, the product may be damaged. In
addition, improper use can result in short circuits, fires or other hazards. Read the instructions
carefully and store them in a safe place. Make this product available to third parties only
together with its operating instructions.
This product complies with the statutory national and European requirements.
All company names and product names are trademarks of their respective owners. All rights
reserved.
Delivery Content
• Webcam
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or
scan the QR code shown. Follow the instructions on the website.
Explanation of Symbols
The symbol with the exclamation mark in the triangle is used to indicate important
information in these operating instructions. Always read this information carefully.
The arrow symbol indicates special information and advice on operation.
Safety Instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information
on proper handling in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will invalidate the warranty/
guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may become
dangerous playing material for children.
• Protect the appliance from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
• Consult an expert when in doubt about the operation, safety or connection of the
appliance.
• Maintenance, modifications and repairs must only be completed by a technician
or an authorised repair centre.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
• If the device gets hot after prolonged use, exit the camera application and let it
cool before using it again.
Operating Elements
1
2 3
4
1 Universal joint
2 Camera lens
3 Lens focus ring
4 USB connection cable
5 Desktop stand / laptop mount
Operation
a) Plug and Play
• Connect the device to a USB port (min. USB 2.0) on your computer.
®
• Windows
automatically starts the installation of the required drivers.
• Follow the on-screen instructions.
- In case you experience problems, refer to your computer support guide.
Make sure you are connected to the Internet, so the software can be downloaded
• Run your desired webcam application.
b) Lens Focus Ring
You can adjust the sharpness of your image by rotating the lens focus ring.
Care and Cleaning
• Disconnect the product from the mains before each cleaning.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a suitable dry, fibre-free cloth, taking care not to scratch the lens cover.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product in accordance
with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the protection of the
environment.
Technical Data
Input voltage / current ................... 5 V/DC (via USB), 200 mA
USB interface ............................... 2.0
Microphone ................................... Built-in
Camera sensor ............................. CMOS
Camera adjustment angle ............ 53°
Camera field of view ..................... 65°
Resolution ..................................... 640 x 480, 30 fps
Operating conditions ..................... -30 to 70 °C, 10 – 95 % relative humidity
Storage conditions ........................ 0 to 50 °C, 10 – 80 % relative humidity
Cable length ................................. 150 mm (with plug)
Dimensions (W x H x D) ............... 45 x 78 x 65 mm
Weight .......................................... 76 g
Supported Operating Systems
Windows ....................................... Windows
Mac OS ......................................... 10.4.8 or above
Linux ............................................. 2.3.6 or above
Android ......................................... 4.0 or above
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represent the technical status at the time of printing.
Copyright 2018 by Conrad Electronic SE.
5
®
TM
Vista
32/64 bit or above
*1616189_v2_0118_fl01_02_m_4L
