Changing channels

The transmitters in the Lynx system transmit the signal wirelessly to MiniVib.
They can transmit on a total of 16 different channels (0-9, A-F). MiniVib and all
transmitters must be set to the same channel so that they can communicate. They
are pre-set to channel 9, and then operate together without alteration.
In some cases, it may be necessary to change the channel setting. If two or more
users live near one another, the alarms can interfere. This can be rectified by
changing the channel settings so that they are different for everyone. Any channel
can be selected except Channel 0. (Channel 0 is reserved for a common alert such
as a fire alarm.)
Chanel LED
0 -
1 orange
2 -
3 orange green
4 -
5 orange
6 -
7 orange green yellow -
8 -
9 orange
A -
B orange green
C -
D orange
E -
F orange green yellow red

Technical data

Frequency:
Number of channels: 15, and a common channel 0.
Battery:
Mains adapter:
Strap:
Other:
Dimensions:
Weight:
6
- - -
- - -
green - -
- -
- yellow -
- yellow -
green yellow -
- - red
- - red
green - red
- red
- yellow red
- yellow red
green yellow red
433.92 MHz AM.
Chargeable NiMH, Varta V 40 H. Use only this type of
battery. Charging time approx 180 minutes. Operation:
approx. 4 days per charging. Battery life at least one year.
To change the battery, contact the place of purchase.
Make: STH. Type: P-001B.
Elastic strap with large adjustment range. Compatible with
normal watchstrap (18 mm). When changing the strap:
release the pin with a needle.
Wash-proof.
Diameter 38 mm, thickness 12 mm.
12 g.
If you need to change the channel on
MiniVib, proceed as follows:
1. Connect the charging terminal
to an electric socket. In order to
access programming mode: hold
down the button while inserting
and removing the charging ter-
minal. Then release the button.
Various LEDs flash, depending
on which channel is set.
2. Change channels by pressing the
button the required number of
times. You step up through the
channels with each press of the
button.
3. To save the channel setting, wait
for 15 seconds until all the lamps
have gone out.
