Preparing Your Combo Album Scanner - Reflecta Combo Album-Scanner Mode D'emploi

Preparing Your Combo Album Scanner

1. Insert and push an SD card into the SD card slot until
the card locks in place. Push once again to release
the card. Unit only accepts SD or SDHC card up to a
maximum of 32GB.
2. Load the battery into the scanner as described in the
section "Installing the Battery Pack".
3. Select the media you want to scan. Slide the
photo/film focus switch and photo/film light switch to
the appropriate media.
4. Connect the power adapter to the household electric
power plug, then connect the power adapter to the
scanner via the micro USB cable. Make sure the USB
terminal is inserted in the correct orientation. Do not
use too much force to connect the USB terminal into
the micro USB connector.
5. Press the power button, then the OK button to select
NO (not linked to a computer) on the pop up dialog on
the LCD screen. The photo LED (green) or the film
LED (Blue) will light up depending on the media
chosen.
6. The scanner is now ready for use.
Note:
If you do not see the light from your LCD screen, slide the
-9-
EN
