How to connect the electronics
Battery
Battery positive +
Battery negative -
Switch
Receiver cable (TH)
Sensor cable connector
Receiver
CH1: Servo
CH2: Speed Control
Servo
Throttle range
Rock Crawler: Backward Zone
Full throttle
Normal EP Car: Brake and backward zone
Forward
Neutral zone
Full brake/reverse
Neutral point
Brake/reverse zone
Neutral point
Forward
Neutral zone
Full throttle
Full brake/reverse
