Timed Pulse Counting Adjustment; Internal Storage Recording Mode; Bluetooth Recording Mode; Battery Life Indicator - REED R8008 Manuel D'utilisation

Timed Pulse Counting Adjustment

1. While in Timed Pulse Counting mode press and hold the Pulse
Button for 2 seconds. The icons "Pulse" and "Time" will appear on
the LCD with the value 060 indicating 60 minutes. The maximum
time value is 999 minuets.
2. Press the Up and Down Buttons to adjust the flashing digit.
3. Press the Enter Button to proceed to the next digit, and press the
ESC button to return to the previous digit.
4. When the time has been set press the Enter Button to begin
measuring Dose Accumulation for the set amount of time. The icon
"TIME" will appear on the LCD.
5. Press the Up and Down Buttons to adjust the display value. The
meter will beep when the set time is up.
6. Press the Pulse Button to pause the timer, and press it again to
resume measuring. Press and hold the Pulse Button to re-enter the
Timing setup Mode.

Internal Storage Recording Mode

When taking a measurement, press the Save button to enter Recording
Mode. A record will be saved every other minute. A maximum records
saved is 4000 groups of data. When the memory is full the meter will au-
tomatically save over the first measurements. Press the Save button again
to exit Recording Mode.

Bluetooth Recording Mode

When the meter's Bluetooth functionality is turned on, press the Save
button. This will transmit all measurements to a PC via Bluetooth. For
instructions on connecting a device via Bluetooth to your PC please refer
to your PC's instruction manual.

Battery Life Indicator

To check on the meter's battery status, press the Battery Button. Press
the ESC Button to return to normal measuring. If the batteries die then all
internal records will be lost.
