INDICATOR LIGHT

BLUE – Battery Charging
FLASHING BLUE – Battery Full
NO LIGHT – Off
FLASHING RED – Input over voltage, unit over temperature, or
improper connection
WHAT IS MPPT?
MPPT stands for Maximum Power Point Tracker. The Solar Charging
Optimization Module is an external MPPT and when installed properly,
actively monitors the energy source you're using to charge the Goal Zero
Yeti Lithium and optimizes the source to maximize power, resulting in up to
40% faster charge times, especially from solar panels. You may also notice
better charge times from AC when utilizing the Yeti Lithium's AC charging
cable plugged into the module.

FREQUENTLY ASKED QUESTIONS

Q: How many solar panels can I plug into the module?
A: There are three inputs on the module that can be used at the same time;
however, do not exceed more than 22V under standard use, as this
can result in damage to the Yeti Lithium and potential bodily injury. We
recommend chaining solar panels in parallel (positive to positive, negative
to negative, etc). We've taken the guesswork out of chaining when using
Goal Zero Boulder Solar Panels, the 8mm blue-ringed connector and
combiner cables properly chain our panels together for approved use
with the Yeti Portable Power Stations. Please call our solar experts at
888-794-6250.
Q: Can I plug solar panels into the module and the Goal Zero Yeti Lithium
input ports at the same time?
A: Yes; however, we recommend using the module's inputs for solar panels
since it can optimize the charging efficiency up to 40%. You may even
notice up to 20% more efficiency when charging the Yeti Lithium from
the wall when using the module.
Q: Can I use non-Goal Zero Solar Panels or a custom wiring solution or any
solar configuration that may be over 22V open circuit voltage
A: Please call our solar experts at 888-794-6250.
6

TECHNICAL SPECIFICATIONS

Yeti Lithium MPPT Expansion Module
25 Amp MPPT Charge Controller
Charges the following:
GOAL ZERO Yeti 1000 @ Max Input
GOAL ZERO Yeti 1400 @ Max Input
GOAL ZERO Yeti 3000 @ Max
Input
Ports: Do not exceed 22V input under standard use
8mm Charging port
Power Pole charging port
Expansion Module Connector
(Output)
General:
Weight
Dimensions
Warranty
Certs
Approx. Charge time:
3.5 hrs
5 hrs
10 hrs
14 - 22V, Do not exceed
150W per port
14 - 22V
25A MPPT charge controller
1.3 lbs (583 g)
10.25 x 3.3 x 1.5 in (26 x
8.4 x 3.8 cm)
12 months
