Code Retrieval (continued)
5. Starting with the number 1 key,
press and release each number key
on the keypad in the following
order (1-9, then 0). The number
that causes the illuminated
ON•OFF
ON•OFF key to blink is the first
number of the code. As you find
each number of the code, refer to
the code boxes below and write
them down for future reference.
Note:
number 1; all VCR codes begin
with the number 2; all DVDs, the
number 3; and all satellite
receivers and cable boxes, the
number 5.
6. Repeat step 5 until you have
ON•OFF
retrieved all four numbers in
the code.
7. After the fourth number is
retrieved, the illuminated ON•OFF
(BLINK)
key blinks briefly, then turns off.
8. To exit the Code Retrieval Mode,
GO BACK
press and release the GO BACK
key at any time.
9. If you press an invalid key during
the Code Retrieval process, the
remote will not respond. If you do
not press a valid Code Retrieval
key (TV, VCR•DVD, SAT•CBL,
INFO, GO BACK), Code Retrieval
times out after 15 seconds. The
illuminated ON•OFF key blinks
four times, and then turns off.
TV CODE
1
·
VCR DVD CODE
·
SAT CBL CODE
5
Using the Remote to
Control Your Components
Because this remote controls more than one component, you
must first "tell" the remote which component you wish to
operate. That means, if you wish to operate your TV, you
must first press the TV key to put the remote in the TV Mode.
The remote stays in the chosen component mode (such as TV
Mode) until you change it. If your remote is in TV Mode, you
must change the mode in order to operate your DVD or VCR,
satellite receiver or cable box. For example, if you are in VCR
Mode, and you wish to turn off your TV, you must press the
TV key first before pressing the ON•OFF key.
12
11:46 AM Page 12
All TV codes begin with the

On-screen Menus

Accessing and Selecting Menu Items

Today's advanced components use on-screen menus to help
you navigate through all their features and functions. While
this remote cannot access every menu system of every
component model, it does offer some menu functionality.
To use a component's on-screen menu system, you first have
to put the remote in Menu Mode.
1. Make sure your components are
•
•
SAT CBL
VCR DVD
turned on and your TV is set to
TV
the component's input. (Use the
INPUT key to toggle through
video sources when in TV mode.)
ON•OFF
MENU
2. Press the component key whose
menu you want to access.
3. Press the MENU key. The
illuminated ON•OFF key blinks,
(BLINK)
indicating you are in the Menu
Mode.
VOL & CH
4. Use the VOL+/- and/or CH+/-
keys to navigate through the
on-screen menu system.
5. To make a selection from
the on-screen menu, press
MENU OK
the MENU or OK key to
select the highlighted item.
! If the remote doesn't respond,
TIP:
check to see that the illuminated
ON•OFF key is still blinking. Note: it
times out after 20 seconds. If this
happens, just press the MENU key
again, and then retry your selection.

Exiting a Menu Mode

The remote automatically times out of Menu Mode after
20 seconds of inactivity (no keys being pressed). At that
time, the remote clears the displayed menu from the TV.
If you want to exit the Menu Mode yourself, press the
corresponding component key on the remote (TV, VCR•DVD,
SAT•CBL). The illuminated ON•OFF key turns off.
Sleep Timer (Select Models Only)
This feature automatically turns off your TV at a duration you
choose from 1 to 99 minutes. The Sleep Timer only works if
you have found a code that controls your TV. The timing
mechanism for the Sleep Timer is built into your universal
remote control. To program the Sleep Timer, follow these steps.

PROGRAMMING THE SLEEP TIMER

TV
1. Press and release the TV key.
2. Press and hold the SLEEP key for
ON•OFF
SLEEP
three seconds. The illuminated
ON•OFF key turns on.
3. Release the SLEEP key.
4. Using the number keys, enter the
desired time in minutes (from 1-99
minutes). To set the timer to a
ON•OFF
number under 10 minutes, first
press 0 and then the desired
number (e.g., 05 for five minutes).
The illuminated ON•OFF key
(BLINK)
blinks with each keypress.
