3 - GENERAL VIEW AND MAIN COMPONENTS
Item Description
Number
5 Sealed Chamber
7 Gas Inlet
10 Supply System
11 System Return
16 Modulating Fan
19 Combustion Chamber
22 Burner
27 Copper Heat Exchanger
28 Exhaust Manifold
29 Exhaust Outlet Manifold
32 Heating circulating pump
36 Automatic Air Vent
44 Gas Valve
81 Ignition and Detection Electrode
95 3 Way Diverter Valve
114 Water Pressure Switch
209 Hot Water Tank Delivery
210 Hot Water Tank Return
278 Double Sensor - High Limit NTC
297 Air Pressure Switch
364 Condensation Coupling
Unit Weight
Shipping Weight
LBS
CHB 100 61
CHB 130 65
CHB 100 65
CHB 130 69
7
Kg
27.5
29.5
29.5
31.5
