6. Technical data
The foot switches XPEW described in this manual are certified II 2 GD and can operate into the classified
zones 1 and 2 for gases or 21 and 22 for dusts.
6.1. Features
Certificate Europe (ATEX)
Standards accordance
Ex-codes
Temperature range
IP rating
Material
Rated operational
specification of the contact
Type of contacts
Short-circuit protection
Cable entry
Electrical connection
Mechanical endurance
6.2. Additional technical data
Prodcut code
XPEWM110
XPEWM111
XPEWM211
XPEWR110
XPEWR111
XPEWR211
7. Safety instructions
The following safety instructions should be read in conjunction with the following standards:
standard NF C 15 100
IEC 60079-14 (Electrical installations design, selection and erection)
standard IEC 60079-17 (Electrical installations inspection and maintenance)
standard IEC 60079-31 (Equipment dust ignition protection by enclosure "t").
decrees, laws, directives, circulars of application, standards, rules of art and any other documents
concerning its place of installation
It is strictly forbidden to change anything on and in the product without our prior agreement
XPE004A12-07
01/12/2016
INERIS 04ATEX0042
EN / IEC 60079-0
EN / IEC 60079-1
EN / IEC 60079-7
EN / IEC 60079-31
Ex d e IIC T6 Gb
Ex tb IIIC T85°C Db
Ambient : -20°C ... +60°C
Storage : -40°C ... +70°C
IP 66 according to IEC 60529
Zinc alloy
Ue = 240V, Ie = 6A, Ui = 400V
AC-15, A300 – Ue = 240V, Ie = 3A
DC-13, Q300 – Ue = 250V, Ie = 0,27A
Snap-action – See table below
By fuse 6 A gG
1 cable entry PG16 for cable 10 to 15 mm, 1 cable entry with blind
plug
Screw terminal, conductor of 1 x 2,5 mm
5 millions operations
Contact operation
1 step
1 step
2 steps
1 step
1 step
2 steps
Operating instructions
Foot switch - series XPEW
2
or 2 x 1,5 mm
Contact
Color
1 NO + 1 NC
Blue
2 NO + 2 NC
Blue
2 NO + 2 NC
Blue
1 NO + 1 NC
Orange
2 NO + 2 NC
Orange
2 NO + 2 NC
Orange
ENG
2
8/12
