CSW65 Installation Manual
Environmental Specifications:
Description
Use
Temperature
Humidity
Altitude
Shock
Vibration
Material Group
Pollution Degree
Overvoltage Category
Class
Level of Insulation:
Dielectric Strength testing is carried out as follows:
Primary mains circuit to earth: 1,500VAC
Primary mains circuits to secondary: 3,000VAC
Output to earth isolation: 500VDC
Safety Approvals:
IEC/EN/UL/CSA 60950-1
CE mark.
CE marking when applied to any CSW65-xx product indicates compliance with the Low Voltage Directive, the RoHS
Directive and the EMC Directive. These products are component power supplies for building in to an end system.
NOTE: EMC Performance:
This product series is tested to EN55032. Final compliance must be checked in the end system.
Input Parameters:
Standard
Nominal input voltage
Input voltage range
Input frequency range
Maximum input current
Input Connector CN1: 3-pole terminal block, pitch 9.5mm, rated at 20A/300V
Terminal Number
1
2
3
Output Parameters:
Output channel Vout (V)
CSW65-5
CSW65-12
CSW65-15
CSW65-18
CSW65-24
CSW65-28
CSW65-48
CSW65-54
Output Connector CN2: 2-pole terminal block, pitch 9.5mm, rated at 20A/300V
Terminal Number
1
2
Page 7 of 10
Operation
Indoor
-10°C - +70°C (derating at 2.5%/°C above 50°C)
5 - 95% RH, non-condensing
5000m (EN60950-1)
23.52m/s 2 (10 - 55Hz constant sweep 1 min X, Y, Z for 1 hour)
60601-1
100-277VAC
90-305VAC
47-63Hz
2.5A (115VAC)
Function
AC Ground
AC Neutral
AC Line
Adjustment
range (V)
5
12
15
19 All
24 Factory set
28
48
54
Function
DC Output Positive
DC Output Negative
11
2
<196.1m/s (20G)
IIIb
2
II
I
60950-1
Output Maximum
current (A) power (W)
8.0A 40
5.42 65
4.34 65
3.62 65
2.71 65
2.33 65
1.36 65
1.21 65
th December 2017
Storage
-
-20°C - +85°C
5 - 95% RH, non-condensing
-200m - 5000m
