PARTS SUBSTITUTIONS & MODIFICATIONS
Parts substitutions and modifications are authorized TDK Lambda service personnel only. For repairs or
modifications, the instrument must be returned to TDK Lambda service facility.
AC INPUT
Do not connect RFE1000 units to mains supply exceeding the input voltage and frequency rating. The input voltage
and frequency rating is: 100-240V~, 50/60Hz. For safety reasons, the mains supply voltage fluctuations should not
exceed +/-10% of nominal voltage.
ENERGY HAZARD
The main output of RFE1000 units is capable of providing hazardous energy. Due to hazardous energy level
the output and connections therefore must not be user accessible. Manufacturer's final equipment must provide
protection to service personnel against inadvertent contact with output bus bars.
FUSE
Internal fuse is sized for fault protection and if a fuse was opened it would indicate that service is required. Fuse
replacement should be made by qualified technical personnel.
RFE1000 unit's fuse ratings are described below. F101: F20A H 250Vac; F102: 6.3A 400VDC.

OVERCURRENT PROTECTION:

A readily accessible branch circuit over-current protective device rated 20A max. must be incorporated in the
building wiring.
SYMBOLS
CAUTION Risk of Electrical Shock.
Instruction manual symbol. The instrument will be
marked with this symbol when it is necessary for
the user to refer to the instruction manual.
Indicates hazardous voltage.
Indicates ground terminal.
Protective earth; protective ground. Indicates the
terminal which is intended for connection to an
external conductor for protection against electric
shock in case of a fault.
Denotes hazard. An attention to a procedure
is called. Not following the procedure correctly
could result in personal injury. A WARNING
sign should not be skipped and all indicated
conditions must be fully understood and met.
Denotes hazard. An attention to a procedure
is called. Not following the procedure correctly
could result in damage to the equipment.
