Switch off the machine and
wait until the machine
has come to a complete
standstill before changing
Adjust the speed to the material to be drilled
and the drilling diameter.
_
For drilling in wood, choose a high speed.
_
For drilling in metal and plastics, choose a
lower speed as the drilling diameter increases.
Instructions for use
_
Use waste material to practise your skills and
to learn operating the machine first.
_
When drilling through, adjust the table to
make sure that the drill is alligned with the
opening in the centre of the table.
If required, mark the position on the front side
of pillar and table in case the table should be
set in the same position at a later time.
_
Securely tighten the workpiece. Toppling,
turning or sliding not only results in a rough
drilling hole, it also increases the risk of the drill
breaking off.
_
Use a piece of waste wood as a backup to
reduce the risk of the workpiece splintering and
to protect the drill tip.
_
Place flat workpieces on a wooden
underground and clamp securely to the table to
prevent them from turning. Support workpieces
that are irregular of shape and cannot be put
flat onto the table.
_
Use the lift handles to bring the drill lift
downwards.
Slowly feed the dril into the workpiece.
_
Drill slowly when the drill is about to break
through the workpiece to prevent splintering.
Switching on and off (fig. A)
_
To switch the machine on, set the on/off
switch (1) to 'I'.
_
To switch the machine off, set the on/off
switch (1) to '0'.
Using the laser (fig. H)
the speed.
The laser beam is used to indicate the centre
location of the drill hole in case you have to drill
several holes in workpieces of the same
thickness.
_
Place the table (5) in a horizontal position.
_
Make sure that the drill and the opening in
the table are aligned.
_
Place the workpiece on the table.
_
Lower the drill bit until it touches the
workpiece.
_
Switch the laser (33) on by operating the
on/off switch (10).
_
Check that the laser cross hairs (34) align
with the centre of the drill hole as marked on
the workpiece. If necessary, adjust
the laser by hand.
_
Follow the "Instructions for use" to perform a
drill hole.
_
After use, switch off the laser.
CLEANING AND MAINTENANCE
The machine does not require any special
maintenance.
_
Regularly clean the ventilation slots.
Lubrication
_
Turn the drill shaft to the maximum drilling
depth once per 3 months and grease it slightly
with oil.
TECHNICAL DATA
Mains voltage V
Mains frequency Hz
Power input W
No-load speed min-1
Number of drilling speeds
Chuck capacity mm
Table dimensions mm
Pillar height mm
Weight kg
Level of sound pressure measured according
to EN 61029-1:
LpA (sound pressure) dB(A)
16
230
50
500
280-2,350
9
3-16
170 x 170
610
19
< 70
