Proper Use - Pentatech EW 01 Mode D'emploi

Contents
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18
. . . . . . . . . . . . . . . . . . . . . . .
2. Proper use
. . . . . . . . . . . . . . . . . . .
3. Package contents
. . . . . . . . . . . . . . . . . . . . . .
4. Description
. . . . . . . . . . . . . . . . . . . . .
5. Technical Data
. . . . . . . . . . . . . . . . . . .
6. Safety instructions
. . . . . . . . . . . . . . . . . . . .
7. Commissioning
. . . . . . . . . . . . . . . . . . . . . . . .
8. Location
1. Introduction
Read through this user manual completely and carefully. The user manual
is an integral part of the product and contains important information
about operation and handling. Always observe all the safety instructions.
If you have any questions or are unsure about using the equipment, ask a
specialist or obtain information on line at www.pentatech.de. Keep this
manual in a
safe place and pass it on to third parties if necessary.

2. Proper use

The Electronic Watchdog EW 01 consists of main unit EW 01A, remote
control EW 01R and mains adapter Type GPE125-120050-2.
The primary use of the unit is the simulation of a guard dog in order to
deter a ppotential break-in to property.
The unit is placed inside the property, next to the location to be monitored
(eg. front door, patio door) and it can be armed by pressing a button on
the unit or on the remote control. The sensor in the unit can detect
movement on the outside of the wall (eg. somebody approaches the front
door) which triggers the simulation of a barking sound. Alternatively a
chime or a siren sound can be generated. The siren sound can also be
manually triggered by pressing the panic button on the remote control.
The unit can be expanded with optional accessories. Up to 6 wireless
detectors (reed contacts to monitor doors or windows, or PIR-detectors to
monitor movement in rooms) can be enrolled into the unit. A second
remote control can also be added.
The unit is powered through the 12 V DC mains adapter which is
connected to 230 VAC, 50 Hz. To maintain operation in case of mains
power failure 8 AA size batteries (not supplied) can be installed. The
remote control is powered by a 3V CR2032 size button cell.
The electric watchdog is intended for indoor use within private
households.
Any other use or change of the appliance is improper use. No liability
shall be assumed for consequential damage as well as damage which is
caused by improper use or incorrect operation.
This appliance is not intended to be used by people (including children) with
GB - 18
. . . . . . . . . . . . . . . . . . . . . . . . . .
9. Use
Page 18 10. Adding optional wireleess components
11. Power LED and battery change
Page 18
Page 18 12. Maintenance + cleaning
13. Declaration of conformity
Page 19
14. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21
Page 19
Page 19 15. Warranty
16. Fault finding
Page 20
restricted physical, sensory or mental capacities, or a lack of experience
and/or knowledge, unless they are supervised by, or receive instructions how
to use the appliance from, a person responsible for their safety. Children
must be supervised in order to ensure that they do not play with the
appliance.
3. Package contents
After unpacking immediately check that the delivery is complete and that
the equipment is undamaged.
#
Main unit EW 01 A
#
Mains adapter (packed in the bottom of the box)
#
Remote control EW 01 R with key ring
#
CR 2032 battery
#
2x screw
#
2x wall plug
#
Warning sticker
#
User Manual
4. Description
Main unit EW 01 A
1 main unit
2 speaker
3 range adjuster
4 power switch and volume adjuster
5 arm LED
6 power LED
7 hanging slot
vicinity Otherwise there is a risk of severe hearing damage!
!
Do not damage any cables or pipes for gas, electricity, water or telecoms
when you are drilling or mounting the device! Otherwise there is a risk to
life and limb!
!
Handle the mains adapter cable carefully! Place all cables in such a
. . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
(see Fig. A)
8 LEARN button
9 switch
!
Page 20
Page 20
Page 21
Page 21
Page 21
Page 21
Page 21
position that they cannot be
damaged or become a trip
hazard. Otherwise there is a
risk to life and limb!
Do not allow the device to
