Your Ramset RA27 Tool uses only the Ramset fasteners and loads shown below or
listed for the tool in the Product Catalog.
Never use any other types of fasteners or strip loads in the Ramset RA27 Tool. Use of other
types of fasteners or loads may cause unintentional load discharge, damage the tool, cause
poor fastening performance, or create a risk of serious injury to the operator or bystanders.
FASTENERS
Fasteners for the RA27
Fastener Series Description
1500 Series
1500SD Series
SP Series
TE Series
SDC/SPC Clips
Fasteners for the RA27MAG
TE__X Series
Maximum fastener length for the RA27 is 1-1/2 inches. Contact Technical Support for
other fasteners that may fit in the tool.
LOADS
Ramset RS27 strip loads are specially made for use in the Ramset RA27 Tool.
RS27 10 SHOT STRIP LOAD
POWER CATALOG
LEVEL
NUMBER
COLOR
3
3RS27
4
4RS27
5
5RS27
DANGER
.0300" head, 0.145" shank dia.
.0300" head w/ 7/8" washer, 0.145" shank
.0300" head, 0.150" shank dia.
.0320" head, 0.157" shank dia.
.0300" head ceiling clip assembly
.0320" head, 0.157" shank collated in
white colored strip of 10
The power level of the load is indicated by
the number marked on each box, the color
of the box, and the color on the tip of each
load. As the number increases, the power
level also increases.
Always perform the center punch test
described on page 3 to test the base material.
LOAD
CASE
COLOR
Always make a test fastening using the
lowest power level first. If more power is
Green
Brass
required to set the fastener, use the next
Yellow
Brass
higher power level until the powder level
Red
Brass
necessary to drive the fastener is reached.
FASTENERS / LOADS
Max. Length
1-1/2"
2"
1-1/4"
1-1/4"
1-1/4"
1-1/4"
FASTENERS / LOADS
7
