WYLER Remote Display Mode D'emploi page 7

Data format
Data format OUT-Port
Measurement active
Reply
0sssH =
0nnnnnnnnH =
Remarks:
The last digit of the angular value indicates if the measured value is a individual
measurement or a differential measurement.
(Even value = individual measurement, odd value = differential measurement)
0ccH = Checksum of the digits‚ sssnnnnnnnn'
No data
Reply [384000000000F<cr>]
Format of transmission
asynchrony, 7Bit, 2 Stop bits, no parity, 9600 Baud
T D
ECHNICAL ATA
1. Power supply
External power supply
2. Measuring range
depending on the instrument, sensor connected
3. Resolution
depending on the instrument, sensor connected
4. Various
Dimensions:
Weight:
Temperature range (storage):
[sssnnnnnnnncc<cr>]
0 .. 255 - Running number
+999999999 - Positive Overrange
-999999999 - Negative Overrange
other value - Angle in 10
8,0 to 24,0 V DC, connected to Port A or B, or OUT
72 mm(L) x 44 mm(H) x 21mm(W)
125 gr.
-20 to +70°C
Page 7 of 10 pages
-8
rad
