10
9
8
1. Front Camera
2. Speaker Phone
3. Light sensor
4. LCD
5. Return Key
6. Home Key
7. Menu Key
8. MIC
Note regard the use of micro-SIM adapter on TREVI products
The slots for SIM cards are designed to accommodate only the consideration SIM format.
The use of SIM (micro or nano) with its adapter and 'not recommended as it can cause
damage to the device and the micro/nano SIM itself.
Warning:
• Trevi not liable for damages caused by the use of adapters for micro/nano-SIM.
• TREVI reserves the right to refuse free assistance in warranty on defective products that
have 'caused by the use of the SIM adapters for micro/nano-SIM.
• Do not insert memory card into the SIM card slot.
11 12
1 2 3
4
7 6 5
Nano SIM card with adapter
14
13
16
9. Volume - Key
10. Volume + Key
11. Earphone Jack
12. Micro USB Jack
13. Power Key
14. Flash Light
15. Back Camera
16. Speaker
42
15
