Battipav srl
CHECKING BEFORE USE
CAUTION
THE CLASS PLUS MACHINE HAS BEEN DESIGNED
FOR WORKING EXCLUSIVELY WITH WATER.
Before any cutting operation, make sure that the
13
water level inside the tank is correct.
CAUTION
ADJUSTMENT OF COOLING WATER
Through an on-off valve placed on the disk protection,
the water flow can be adjusted according to the type
of material to be cut.
An innovative cooling system makes it possible and
allows the disk to be always wet.
CONNECTING TO POWER SUPPLY
CAUTION
The machine is to be connected to the power supply
by a residual current circuit breaker (RCCB) with the
following characteristics:
RCCB
Transformer
N.B. To ensure correct functioning, periodically
check the efficiency of RCCBs by pressing the
push-button on the front of the device.
• Make sure that the section of the power supply
cable cores has been measured according to the
starting current and its length.
For cables up to 50 m long, a section of 2.5 mm
is enough.
• Before connecting the machine to the power
socket, check that the power supply voltage
corresponds to that shown on the plate on the
machine.
• The machine must be connected to an effective
earth wire.
In case of doubt, do not connect the machine.
In 10 A Id 30 mA
230 V 50 Hz 2000 W
Transformer
2
BLADE ASSEMBLY / DISASSEMBLY
Before performing any operation or adjustment,
disconnect the machine from the supply mains.
Loosen both nuts located on the blade cover guard
and remove it.
Remove the blade fixing nut using the 19 mm
spanner and the 5 mm Allen wrench.
CAUTION
THE BLADE FIXING NUT HAS A LEFT-HAND
15
THREAD.
After dismantling the blade, clean the blade flanges
carefully and check them for wear.
Grease any surface with fine oil and install the new
blade. Check for correct direction of rotation as
clearly indicated on the tool.
CONTROL DEVICES
CAUTION
The CLASS PLUS machine is equipped with a
16
control board made up of:
1) START BUTTON (GREEN COLOUR):
Press the button fully to activate machine
starting.
2) REGULAR STOP BUTTON:
Press the button fully to activate machine
stop.
3) DEVICE FOR DISCONNECTION FROM THE
17
MAINS (PLUG):
Machine power supply point.
During the maintenance phases, take out the
device plug in order to disconnect the machine
from the mains.
4) LASER MARKER (OPTIONAL ON CLASS
18
PLUS 850, CLASS PLUS 1050, CLASS PLUS
1300)
It projects the cutting line on the table.
It is enabled when the machine is connected
to the mains.
GB
