Assembly with a 32 mm hose connector. This is pushed
directly over the connector adapter and fastened with
the hose clip. Fig. 7
»
Assembly with a 38 mm hose connector. Fig. 8,9,10 First
push the rubber reduction fitting 32/38 over the connector
adapter. Then push the 38 mm hose over the reduction
fitting and fasten with a hose clip.
Interline Solar Heater Dome Pro
Connection between solar collector and pool:
For pools with a Ø 32 mm or Ø 38 mm swimming pool hose,
follow the instructions below:
»
Attach the hose to the return connector on the underside
of the solar collector.
»
Use a hose clip to connect the hose to the return connector
(see Fig. 13)
A: Pool return hose
B: Reduction fitting, if required
C: Hose clip
D: Return connector
Correct positioning of the solar collector
Attach both legs to the underside of the device and adjust position
according to the sun. Make sure the surface is stable and level.
The device should be assembled as shown in Fig. 14.
A:
Swimming pool hose to the pool
B:
Swimming pool hose from the filter / pump
C:
Return connector
D:
Connector flow
Make sure that all hose connections are watertight and the hose
is not kinked or have any sharp corners. It the hoses are not
watertight, check whether the O rings are correctly positioned
and all connec- tions are screwed together firmly. Do not over-
tighten the hose clips (15kg torque).
Connecting several collectors:
If you would like to increase the heating power, you can connect
several collectors together. For this you will need a additional
swim- ming pool hose Ø 32/38 mm.
We recommend connecting a maximum of 2 collectors,
depending on the power of your filter unit.
We definitely recommend use of a bypass set (Fig. 15)
Not only does this help optimal control of heat output,
it also helps targeted control of the water flow rate,
depending on the power of the filter unit.
4 INITIAL USE
Once the solar collector is assembled and the hoses are
connected to the filter pump and the pool, open the water
supply and ensure that water is flowing through the hose. Then
turn on the filter system. Air bubbles will rise from the inlet
nozzle in the pool. This happens as the air is expelled from the
solar collector. If this continues formore than 2-3 minutes, check
the tightness of the connections in your system.
Please note: Cover your pool overnight to avoid loss of
heat.
5 TROUBLE SHOOTING
Problem
Cause / Solution
»
The pool does not
Make sure that water is flowing
warm up.
through the hoses.
»
Has it been sunny enough?
»
Exploit the maximum amount of
sunlight and increase the running
time of the filter pump.
»
Cover your pool overnight to
avoid loss of heat.
»
It is possible that you may need
several solar collectors.
»
No bubbles appear
Check the filter system and ensure
after the equipment
that water from the pool is flowing
has been attached to
through the filter pump, then
the pump.
through the solar collector and
finally through the connect- or
hose back to the pool.
»
Air bubbles come out
Check the connector hoses for any
of the pool return
damage.
»
after the pump has
Check that the hose clamps have
been turned on.
been properly tightened.
»
Water escaping.
Check the seals in the system of
pipes.
»
Check whether you have
tightened the hose clamps tightly
enough.
»
Check the connector hoses for any
cracks.
5
