DASHBOARD
+12V
L1
2,5mm²
2
1
SWITCH
5AT915-02
TO 5200 Control Box
RELAY
87
87A
86
85
30
Thule Awning Control Box
Warning Codes LED
1 x
Power on
2 x
Motor not
connected
3 x
Motor short
circuit
4 x
Motor
blocked/end
5 x
Motor
time out
6 x
< 9V
7 x
> 18V
8 x
Button in & out
1 2 3
1,5mm²
Yello: Ø 6
Blue: Ø 2,5
Red: Ø 1
Fuse
20A
4
5
6
7
P.4
P.5
M
BATTERY 12V DC
2,5mm²
®
!
AWNING
9
