4
062.0550 Flat panel stand 1310-1510mm, max. 55 inch (max. 30 kg)
SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands
SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands
MOUNTING INSTRUCTIONS
3
2
MON.0025
5a | M6x16 | 6x
5b | M6x40 | 2x
T +31 (0)88 70 60 100 • E info@smartmetals.nl • W www.smartmetals.nl
T +31 (0)88 70 60 100 • E info@smartmetals.nl • W www.smartmetals.nl
4
MON.0030
6a | M4 | 4x
6b | M6 | 4x
6c | D15xd6.4xh5 | 4x
6d | M4x10 | 4x
6e | M4x20 | 4x
6f | M6x20 | 4x
1
