PRO-CUT BLADE SYSTEMS - 951V2-D-BL on all Flex Wing models from January 2011
PRO-CUT BLADE SYSTEMS - 951V2-D-BR on all Flex Wing models from January 2011
16
Item Part No
1 1/2F
2 12x114FBZP
3 12x3FBZP
4 9GT-USS
5 9GTB/A
6 BLDB-335
7 DF-BMP
8 FWM20
9 M20
10 M20x60BZP
11 NTSB12C
12 12T-BBS
13 12T-LBB
MACHINE
12000FW-HD
18000FW-HD
Item Part No
1 1/2F
2 12x114FBZP
4 9GT-USS
5 9GTB/C
6 BLDB-335
7 DF-BMP
8 FWM20
9 M20
10 M20x60BZP
11 NTSB12C
12 12T-BBS
13 12T-LBB
14 12x3FBZP
MACHINE
12000FW-HD
18000FW-HD
