3.4
Operating conditions
The PSM MID measuring module may be operated only within the following operating conditions
as well as the conditions specified for the power supply:
Operating voltage
Frequency
Input current
Ambient operating temperature
Operating humidity range
Protection category
4
Assembly
4.1
Assembly instructions
The PSM MID measuring module is assembled as shown in fig. 2.
The PSM MID measuring module must not be installed in a vertical mounting position and also
not upside down in the enclosure.
Ensure good access to the front of the unit so that the display is easy to read.
5
Installation and operation
5.1
Operating and display elements
The operating and display elements are shown in fig. 3.
Key for fig. 3
1
"Infeed 1" MID display
2
"Infeed 1" LED
3
Multi-LED for the status display
4
"Esc" key
5
"Return" key
6
Main display, centre
7
"Up" key
8
"Down" key
9
"Infeed 2" LED
10
"Infeed 2" MID display
11
"Infeed 1" connection
12
Connection plug clamping lever
13
"Consumer 1" connection
14
CAN bus connection
15
CAN bus connection
16
"Infeed 2" connection
17
"Consumer 2" connection
5.2
Installation
The electrical connection may be made only on a TN-S network in accordance with the pre-
scribed specifications (see section 3.4 "Operating conditions").
Rittal PSM MID measuring module for CMC III
Assembly, Installation and operation
...
Single-phase 180 V
260 V on L1 or three-phase
50 Hz
16 A (7859.312) or 32 A (7859.332)
...
-25°C
+55°C
...
20%
90% relative humidity, non-condensing
IP 51 according to IEC 60 529
EN
9
