CONTROL PADS ON THE DEHUMIDIFIER

NOTE: The control panel of the unit you purchased may be slightly different according to the models.
3
Comfort
Dehumidifying
Indicator Light
2
Continuous
Operation on
Indicator Light
CONTROL PADS: When you push the button to change
operation modes, the unit will make a single "beep"
sound to indicate that it is changing modes.
1. POWER
Press to turn the dehumidifier on and off.
2. MODE
Toggle between the following features:
NORMAL – Utilize this mode if you would like the
unit to cycle on and off based on the relative
humidity setting you have manually selected. (See
numbers 5, 7 and 8 in the column to the right for
further instruction.) In NORMAL mode, both the
"Comfort" and "Cont." indicator lights will not be
illuminated.
COMFORT – Utilize this dehumidification feature
to automatically keep humidity in the 45%-
55% range based on room temperature. When
operating in this mode the UP/DOWN
will be deactivated and you will NOT be able to set
a desired humidity.
CONTINUOUS (CONT.) – Press to activate the
continuous dehumidifying operation. When
operating in this mode the UP/DOWN
will be deactivated and you will NOT be able to
set a desired humidity. The unit will run non-stop
unless using the bucket to collect water. At which
point, the unit will shut off when the bucket is full.
3. FILTER
The check filter feature is a reminder to clean the
Air Filter for more efficient operation. The "Filter"
light (Clean Filter Indicator Light) will illuminate
after 250 hours of operation. To reset after
cleaning the filter, press and hold the Filter button
and the light will go off, resetting the timer.
3
Clean Filter
Indicator Light
Filter
Comfort
Cont.
Mode
5
Timer "On"
Indicator Light
/ pads
/ pads
8
Turbo
Full
On Off Auto defrost
Timer
6
Timer "Off"
Indicator Light
4. FAN
Control the fan speed. Press to select either Turbo
or Normal fan speed. Set the fan control to Turbo
("High") for maximum moisture removal. When the
humidity has been reduced and quiet operation
is preferred, set the fan control to Normal by
pressing the FAN pad to turn off Turbo fan/light.
5/7. / : UP/DOWN PADS
HUMIDITY SET CONTROL PADS
• The humidity level can be set within a range
of 35%RH to 85%RH (Relative Humidity) in
5% increments.
• For drier air, press the
percent value (%).
• For damper air, press the
percent value (%).
• The recommended standard setting is 45-50%.
You must be on Normal mode to set the humidity
• Cannot be used in COMFORT or
CONTINUOUS mode.
6. TIMER
Press to initiate the Auto on and Auto off feature,
in conjunction with the
timer range is 0.0 to 24 hrs. Timer does not cycle.
8. DISPLAY
Shows the set % humidity level from 35% to 85%
or auto on/off time (0-24) while setting, then
shows the actual ( +/- 5% accuracy) room %
humidity level in a range of 30%RH to 90%RH
(Relative Humidity).
High Fan
Indicator Light
4
Bucket Full
Indicator Light
1
Power
Auto Defrost
Operation
Indicator Light
7
FIG. 1
pad and set to a lower
pad and set a higher
and key pads. The
