PLAN VIEW
5.0 MAKING CONNECTIONS:
5.1 Only connect the Safety Tie-Off Plate to the Safety Engagement Arm using the provided Safety Cable. If the
Safety Cable is broken, remove from service immediately and contact Leading Edge Safety, LLC at 1-888-990-
2990. If the Safety Cable is lost or stolen, contact Leading Edge Safety, LLC at 1-888-990-2990.
5.2 DO NOT hook lifeline to any point except a Fall Arrest or Fall Restraint Tie-off Ring.
5.3 When making connections, only use self-locking snap hooks and self-locking carabineers with this equipment.
Only use connectors that are suitable to each application. Ensure all connections are compatible in size, shape
and strength. Do not use equipment that is not compatible. Ensure that all connectors are fully closed and
locked.
6.0 FALL RESTRAINT TIE-OFF RINGS:
6.1 The Fall Restraint Tie-Off Rings are installed on either side of the Safety Engagement Arm.
6.2 The Fall Restraint Tie-Off Rings DO NOT arrest falls. The user must verify that the FRS, including lanyards, har-
nesses, etc., DO NOT allow the user to fall from any edge.
T R
R
RI EX
APTOR
(30' maximum - Found 15' back
™ I
NSTRUCTION
PLAN VIEW
45° 45°
CL
Range of Use /Work Zone
from leading edge)
45° 45°
4' minimum from
Leading Edge
