1. Mounting plate installation
3.Terminal cover
3mm
1,5Nm
4x M8x20
4Nm
6mm
1.1
2Nm
PZ1
3.1
3
2. Connection of conductors
S32-2500
S32-3150
Further information about the connection of cables available on www.woehner.com
4. External handle and Red-Yellow handle
2
h
h
4
Bars
80x10 (2x)
80x10 (2x)
M12x50
40Nm
19mm
2.1
0,8x3,5
1
4.1
5
4.2
