Page 2
System connection Hose holder Magnetic connection Siphon holes Hose Optical sensor DC Pump Reservoir Tank/sump Power supply Indicator light High waterlevel Normal to low Low waterlevel Too Low or high green light waterlevel green light off waterlevel red light slowly flashing green light fast flashing alarm Safety...
Page 3
Sensor installation 1. Setup • Rinse the pump and parts with clean tap water before installing. • Install the sensor with water level lower than the sensor or in the middle of the sensor. • Plug in the power supply first, then plug in the pump. 2.
Page 5
Sensor installieren 1. Installation • Bevor Sie die Pumpe installieren erst mit Leitungswasser spülen • Installieren Sie den Sensor mit dem Wasserstand geringer, oder in der Mitte des Sensors • Stecken Sie erst den Adapter in die Steckdose, bevor Sie die Pumpe anschließen 2.
Page 6
System connection guide tuyau fixation magnétique trou antisiphon tuyau capteur optique pompe DC réservoir cuve/décantation alimentation Témoins lumineux Niveau d’eau haut : Niveau d’eau Niveau d’eau bas : Niveau d’eau trop bas ou lumière verte, clignotant normal à bas : la lumière verte trop haut : lumière rouge doucement...
Page 7
Installation du capteur 1. Confi guration • Rincez la pompe et les pièces avec de l’eau du robinet avant de procéder à l’installation. • Installez le capteur : le niveau d’eau doit être inférieur au capteur, ou au milieu du capteur. •...
Page 8
Systeem aansluiting Slanghouder Magnetische bevestiging Sifon Slang Optische sensor DC Pomp Reservoir Tank/sump Stroomtoevoer Indicator licht Hoge waterstand: Normale tot lage Lage waterstand: Te lage of hoge langzaam knipperend waterstand: constant groen licht uit waterstand: snel groen licht. brandend groen licht. knipperend rood alarmlicht.
Page 9
Sensor installatie 1. Installatie • Voordat u de pomp installeert moet deze eerst afgespoeld worden met kraanwater. • Installeer de sensor met de waterstand lager of in het midden van de sensor. • Stop eerst de stekker in het stopcontact voordat u de pomp aansluit. 2.
Page 10
Recycle information The symbol of the barred bin printed on the product means that it must be collected separately from other rubbish when it will not be anymore in use. The user, at the end of the life of the product, will have to bring it to a proper rubbish collection centre for electric and electrical devices.
Page 11
Information sur le recyclage Le symbole de la poubelle barrée sur le produit veut dire que l’appareil doit être recyclé. L’utilisateur, à la fin du vie de l’appareil, doit le ramener à un centre de recyclage des appareils électrique. Une alternative est de le ramener dans le magasin lors d’un nouvel achat, sur la base 1 sur 1.
Page 12
Technical details Maximum Flow 280 L/h Water height 220 cm Voltage DC 12 V Power Maximal glass thickness 19 mm Tube length Dealer stamp / Stempel mit Anschrift des Händlers / - Always keep proof of purchase, without purchase note no warranty! Sceau du point de vente / Stempel aankoopadres: - Bewahren Sie den Kassenbon immer auf;...
