210_Error messages and possible solutions

12. eRRoR Messages and possiBle solutions
error Message display/problem cause
Please insert the SD card! There is no SD card inserted into the measuring device TRI-KA.
Inserted SD card is corrupted and cannot be read.
Error: Old MMC card! A MMC card has been inserted into the TRI-KA.
Initialise SD card!
Overvoltage > 1000 V! Switch off! Measuring cables receive a voltage higher than 1000 V!
Check the measuring setup! Measuring cables receive a current higher than 15A!
Overcurrent > 15A Switch off!
Internal error! Internal error in measuring device
Error: Communication of measurement Internal error in measuring device
Error: Open-circuit voltage (xxV) < 5 V! Measuring cables receive a voltage lower than 5 V.
Error: Irradiation too low Irradiation measured by the TRI-SEN is lower than the set minimum
irradiation in the monitoring values for the output measurement
in the TRI-KA.
Error: Irradiation outside tolerance Irradiation measured by the TRI-SEN changes during the characteristics
analysis beyond the set tolerance value in the monitoring values for the
output measurement.
STC impossible Type of the tested module is a thin-layer module.
TRI-SEN data missing! Characteristics analysis was performed without radio connection between
Measuring curve must later be adjusted TRI-SEN and TRI-KA.
manually. The measured TRI-SEN data must later be synchronised with the TRI-KA.
No data for measuring curve TRI-KA cannot find measured data for the respective measurement during
the later synchronisation of the TRI-SEN data.
TRI-SEN has been deactivated before synchronisation.
Data synchronisation failed The later synchronisation of measured TRI-KA and TRI-SEN data has failed.
Measurement not found During synchronisation, no measured TRI-SEN data could be allocated
to a TRI-KA measurement.
TRI-KA measurement file was deleted before synchronisation.
No data or files could be read! TRI-KA cannot load saved measurement file.
Measurement file corrupted
Verification failed! Data format of measurement file does not correspond to data format
of measuring device.
Measurement file was manually manipulated!
Error: Battery voltage too low/ Battery capacity of LiPo battery too low
Device fails to activate
No firmware file found! Could not perform firmware update. File could not be found.
Firmware file could not be opened! Firmware file cannot be opened.
File corrupted
Error formatting! Incorrect type of memory card inserted into TRI-KA
SD card cannot be formatted.
Module to be tested missing Module does not exist in module database.
from module database
Remedy
Insert SD card
Replace SD card
Replace MMC card with SD card
Switch off the device immediately! Check the measuring setup!
Switch off the device immediately! Check the measuring setup!
Contact TRITEC!
Contact TRITEC!
Connect a module or string to the measuring device
Check the measuring setup!
Observe the polarity of the communication lines
Repeat the measurement with higher irradiation!
Check the position of the irradiation sensor TRI-SEN!
Repeat the measurement with constant irradiation
Check the position of the irradiation sensor TRI-SEN!
STC extrapolation is not performed with thin-layer modules!
Synchronise measured TRI-SEN data under menu item "Memory"
Repeat measurement
Position TRI-KA and TRI-SEN within radio range
Repeat measurement
Repeat measurement
Perform Firmware update on measuring device
Delete measurement file in PC software
Perform Firmware update on measuring device
Delete file
Charge measuring devices using the supplied charger
Firmware file Vx_x_x.TFW must be in directory x:\TRI-KA\UPDATE
Firmware file Vx_x_x.TFW must be in directory x:\TRI-KA\UPDATE
Copy new Firmware file Vx_x_x.TFW into directory x:\TRI-KA\UPDATE
Insert SD/SDHC card into the TRI-KA
Use new SD/SDHC card
Perform measurement using the Dummy module "TRITEC" and add missing module to the PC software in
the module database
Install new module database
Inform TRITEC of update to module database
