PennEngineering Haeger 824 WindowTouch4He Manuel D'utilisation page 145

ITEM NO. PART NUMBER
1 15-00449
2 15-01295
3 15-01296
4 15-01297
5 15-01298
6 15-01585
7 15-01586
8 15-01587
9 15-01588
10 15-01589
11 15-01591
12 15-01592
13 15-01596
14 15-02258
15 15-01668
16 15-01669
17 15-01674
18 15-01675
19 15-01677
20 15-01678
21 15-01681
22 15-01705
23 15-02063
24 15-02262
25 15-02493
26 15-02562
27 15-02681
28 15-02995
29 H-169-6
30 H-2535
31 H-2545
32 H-2610
33 H-3738
17-00020 Rev. J
TIS-3 Assembly
DESCRIPTION
SHCS, M3 x 0.5 X 14mm, STAINLESS
ROUND VINYL CAP BLUE 40 .320 X 1/16"
ROUND VINYL CAP GREEN 23 .320 X 1/16"
ROUND VINYL CAP RED .320 X 1/16"
ROUND VINYL CAP YELLOW .320 X 1/16"
COVER, BASE, TIS-2
ROTATION HUB, TIS-2, -3
LOWER TOOL ARM TIS-2, -3
Base Cover, ELECTRICAL TIS-2, 3
COVER, TIS-2, -3 LOWER TOOL ARMS
LOCKING PIN, ROTATION, TIS-2, -3
AXLE, TIS-2, -3 ROTATION
AUTO ARM, LOWER TOOL TIS-2, -3
FHSCS, M5 x 0.8 x 12mm, Steel, Black Oxide
Pin, Dowel, 3/16" x 1/2", Steel, Hardened
NEEDLE BEARING, 1"ID, 1-9/16OD 5/64 THICK
SHCS, M3 x 0.5 x 25mm, Steel, Black Oxide
HHCS, M10 x 1.5 x 25mm, Steel, Zinc Plated
BEARING WASHER 10MM
NEEDLE BEARING 10MM
SLEEVING, BRADED 3/8"ID X 3' H/D POLYESTER MESH
FHSCS, M5 x 0.8 x 16mm, Steel, Black Oxide
Pin, Dowel, 3/16" x 1/2", Plastic, White
SHUTTLE FLUSH NUT MODULE ASSY OT-3 #4/M3-1
Washer, Serrated, M10, Steel, Black Oxide
Pin, Dowel, 3/16" x 1/4", Steel, Plain
CABLE STRAIN RELIEF INSERT, MODULAR 2x6MM
(WEIDMULLER)
Sensor unit, TIS-3, Quick Disconnect, WT4e
Lower Tool Washer
1/4" Quick Disconnect
Bulkhead Coupler Body 1/4" F Quick Disc.
1/4" X 5/32" Brass Reducer
SHCS, M5 x 0.8 x 12mm, Steel, Black Oxide
138
QTY.
2
1
1
1
1
1
1
3
2
1
1
1
1
1
8
1
4
1
2
1
1
4
1
21
1
1
1
1
1
1
1
1
4
