Quick start instruction
Insert a battery (not included in delivery) before the first staring up, connect
the rechargeable battery and load the lamps completely (approx. 6 hrs.) !
Insert emergency power battery / connect rechargeable battery:
1. Open the securing clip and fold it down as described.
2. Open the upper part of the housing.
3. Insert the battery.
Connect plug and socket (lamp head - rechargeable battery).
Close the upper housing and lock the securing clip.
© 2014 Adolf Nissen Elektrobau GmbH + Co. KG
Star-Flash LED 620A/ 627A FÜQ
See detailed information in the operating instructions !
1
ON OFF switch
–
Switching on: Press the key approx. 0,5 sec.
Switching off: Press the key approx. 1 sec.
Star-Flash LED (type 627A FÜQ only):
Are the lamps located in the charging cradle they can only be switched on/off
via the first (master) lamp!
LED status indicator
The LED status indicator (red and yellow) shows different functions
depending on the operating mode:
Charging process
Red LED flashes:
Red LED off:
Red LED flashes fast:
Key confirmation
Red LED flashes as long as the required function (on/off) is activated.
Battery mode
Yellow LED flashes:
Battery monitoring
Yellow LED off:
Yellow LED on:
Yellow LED flashes:
Yellow LED flashes short:
(directly after switching on)
2 3
Battery is charged.
Charging of battery is completed.
Error message.
Lamp without function, rechargeable battery
empty and battery not yet activated.
Rechargeable battery mode.
Battery mode.
Battery nearly discharged.
A full battery is in the lamp.
296202-2 01.2014
