Description and Function

The network tool set somes in a practical case and its comprehensive accom-
modation is the ideal companion for the installation of network components.
To connect a network cable to a network jack or patch panel, the Insertion
Tool for LSA is used, it is the professional and quick assembly of the LSA
contacts. With the help of the crimp plier and the cutting and stripping tool,
you can easily assemble a patch cable itself or crimp a network connector
later on site to a network cable. For checking the correct assignment, the
two-piece LAN cable tester is to be connected by master and remote unit to
each end of a cable. The test result is displayed by the various LEDs. All tools
are clean and tidy conveniently stored in a supplied bag.
2.1

Scope of delivery

CABLE RJ45+RJ11 RJ45+RJ11
TESTER 1
2
3
4
5
OFF ON S 6
7
8
G
MASTER REMOTE
NS-468 NS-468
Warnings against hazards that may result
in material damage in case of non-obser-
vance.
1
2
3
4
5
6
7
8
G
Cutting and stripping tool
Crimping plier
Insertion tool for LSA
LAN cable tester
Bag, User manual
10
