Operating Elements/ Measurements

4.0 Operating Elements and Connections

1. Test lead with safety plug
2. LED for optical continuity test
3. Warning lamp for voltages > 50V
3

5.0 Measurements

5.1 Preparation and safety measures

No voltage on the test object.
Make sure that the test leads are undamaged.
Use the instrument only in clean and dry sur-
roundings.
5.2 Continuity Test
" Connect probes with UUT.
At resistance between 0...500kΩ , optical and
acoustic signal.
