Connecting
Turn the computer off.
1
Do not connect the Mini Port Replicator
in standby or hibernation mode.
Connect the Mini Port Replicator to the
2
connector of the computer with "This side
up" facing upwards.
Disconnecting
Turn the computer off.
1
Do not disconnect the Mini Port Replicator in
standby or hibernation mode.
While pushing the Mini Port Replicator's
2
lock button, pull the Mini Port Replicator out
straight.
CAUTION
You cannot use the LAN port or the external display port on the computer when the
Mini Port Replicator is connected to the computer. Connect the LAN cable, the ex-
ternal display cable, or the AC adaptor to the ports or jack on the Mini Port Replica-
tor.
If devices connected to USB ports (2a, 2b, 2c) does not operate:
· In the case of devices with consumption voltage exceeding 100 mA, or devices for
which the consumption voltage cannot be confi rmed, connect via USB port 1 or
the computer's USB port.
<Only for Windows XP>
· Try disabling the power saving function on the USB 2.0 hub. For information
about enabling/disabling the power saving function, refer to the computer's Oper-
ating Instructions.
When you use the computer that [USB Port] is displayed in [Advanced] menu of the
Setup Utility, confi rm that [USB Port] is set to [Enable].
For more information about the settings and preparations of the peripheral devices,
refer to the peripheral devices' own operating instructions.
ENGLISH
(For information about the position of the Mini Port Replicator
connector, refer to the computer's Operating Instructions.)
Mini Port Replicator
Connector
