ANSMANN Racing ESC Mode D'emploi page 5

Ein-/Ausschalter • On/off switch •
Interrupteur
Servo
Installation diagram
Failsafe mode
In failsafe mode the controller returns to the neutral position, this is shown
by the Red LED flashing.
Battery type selection
The ESC is NiCAD/NiMH and Lipo compatible. To switch between auto
NiCAD/NiMH auto Lipo cutoff
cut off and
set button switching the ESC on. With the set button pressed, switch on the
ESC using the on/off switch, the LED's will cycle between blue and green,
Brake mode selection (Crawler ESC only)
The Crawler ESC has 2 brake modes, standard and Crawler. Crawler mode
automatically gives full brakes in the neutral position. It also reduces the
top speed of the ESC in both directions.
standard mode
To switch between
the ESC is in the neutral position, press and hold the set button. The LED's
What do the LED's mean?
Blue & green
LED's cycling
Red & blue LED's cycling
Red & green & blue
LED's
flashing for 2 seconds
Red
LED flashing
Instructions Car Speed Controller
Akkupack
Battery pack
Bloc batterie
ch. 2
ch. 1
Empfänger • Receiver •
Récepteur
you must press and hold the
crawler mode, at any time when
and
Battery type selection window
Brake mode selection window
Calibration window
Failsafe mode
+ve -ve
Calibration is complete
and the ESC will power the
motor!
Motor
Motor
Moteur
Failsafe mode is activated if there is a loss of signal due to being out of
range or not receiving a correct receiver signal.
to use NiCAD/NIMH cells release the set button when the green LED is lit,
to use Lipo cells release the set button when the blue LED is lit. The ESC will
flash all 3 LED's then return to the neutral position. The Blue LED will be on
solid all the time whilst being used in auto Lipo mode.
will cycle between red and blue, to use the ESC in standard mode, release
the set button when the red LED is lit. To use the ESC in Crawler mode,
release the set button when the blue LED is lit. The ESC is ready to use.
Red & green
LED's on solid
Green LED lit solid
Red LED lit solid
Red & green & blue LED's
on solid
Green & blue LED's lit solid
Red & blue
LED's lit solid
Neutral position in NiCAD/NiMH mode
Full forwards position in NiCAD/NiMH
mode
Full brake/Reverse position in NiCAD/
NiMH mode
Neutral position in Lipo mode
Full forwards position in Lipo mode
Full brake/Reverse position in Lipo
mode
