notice VL 28-37-45_1-reso
Reference
Nb. of speed
VL 28.1
VL 37.1
VL 45.1
ASSEMBLY OF MODEL VL 28.1
1. Front guard
2. Guard securing clips
3. Fan blade
4. Guard lock nut
5. Rear guard
6. Shaft pin
7. Location pins
8. Motor shaft
A. Remove the guard lock nut (4) from the front motor housing.
B. Fit the rear guard (5) by positioning on location pins (7). Secure the guard to the motor body with the
guard lock nut (4).
C. Push the fan blade (3) firmly onto the motor shaft (8) by matching the slots on the base of the blade with
the shaft pin (6). Check that the fan blade (3) rotates freely by turning with your hand.
D. Open the securing clip at the bottom of the front guard (1) and loosen the clip screw. Position the top
clip on the uppermost part of the rear guard (5). Push the top clip down and press the rim of the front
guard.Close the bottom clip and tighten the screw.
10/02/06
11:09
SPECIFICA
SPECIFICA
Air flow (M
2
1440
3
2040
3
3600
DESCRIPTION OF THE APPLIANCE
DESCRIPTION OF THE APPLIANCE
5
Front
guard
4
Speed
control
switch
Page 6
TIONS
TIONS
3
/h)
Dim.of the guard
280
350
450
Oscillation
1
control
knob
2
Tilt
head
3
Rear
guard
1 2
3
4
6
Power (W)
(mm)
35
45
60
8
7
6
5
