1 Operating Elements and Connections

1.1 Interface CPL-3DMX
1 LED for the operating mode
– lighting continuously:
no DMX control or music control
– extinguished to the beat of the music:
music control via the microphone (4)
– flashing steadily:
control by a DMX light controller or
another CPL-3DMX unit
2 DIP switches Nos. 1 to 9 to adjust the DMX start
address; DIP switch No. 10 without function
3 Button for automatic DMX address adjustment
(
chapter 6.2.1)
4 Microphone for music control
5 DMX signal input (3-pole XLR) to connect a light
controller;
Pin 1 = ground, 2 = DMX-, 3 = DMX+
6 DMX signal output (3-pole XLR) to connect the
DMX input of another CPL-3DMX unit or DMX light
effect unit;
Pin 1 = ground, 2 = DMX-, 3 = DMX+
7 Screw terminals for the LEDs (
8 Screw terminals for the operating voltage
The operating voltage must correspond to the volt-
age required for the LEDs connected (12 V min.,
24 V max.)
9 Connection jack for the remote control LC-3
1.2 Remote control LC-3
The remote control is available as an accessory and
not supplied with the CPL-3DMX.
10 Button STAND BY to activate/deactivate the LEDs
connected
11 Button FUNCTION to select various functions de-
pending on the operating mode selected with the
button MODE (12) [
12 Button MODE to select the operating mode
– Stroboscope mode
The LED of the button MODE will not light up.
– Selection of 9 preset colours
The LED of the button MODE will light perma-
nently.
– Selection of 5 colour change programmes
The LED of the button MODE will flash slowly.
– Colour transition mode
The LED or the button MODE will flash rapidly.
Note: For control via the remote control, there must be no
DMX signal at the DMX INPUT (5).
8
chapter 4)
chapter 5.2]
2 Important Notes
The unit corresponds to all required directives of the
EU and is therefore marked with
G
The unit is suitable for indoor use only. Protect it
against dripping water and splash water, high air
humidity, and heat (admissible ambient temperature
range 0 – 40 °C).
G
For cleaning only use a dry, soft cloth; never use
chemicals or water.
G
No guarantee claims for the unit and no liability for
any resulting personal damage or material damage
will be accepted if the unit is used for other purposes
than originally intended, if it is not correctly con-
nected or operated, if it is overloaded or not repaired
in an expert way.
If the unit is to be put out of operation defini-
tively, take it to a local recycling plant for a
disposal which is not harmful to the environ-
ment.

3 Applications

The unit CPL-3DMX is used to control LEDs or LED
chains requiring an operating voltage between 12 V
and 24 V . The consumption of the LEDs connected
must not exceed 1.5 A per channel (R, G, B). The fol-
lowing items from the product range of "img Stage
Line" can be operated with the CPL-3DMX, e. g.:
Chains with RGB LEDs
(emission of red, green and blue by one LED respectively, allow-
ing any combination colour)
LEDL-9/RGB
LEDM-3/RGB
LEDS-5/RGB
LEDS-5MP/RGB
LEDS-5WP/RGB
Chains with red (RT), green (GN) or blue (BL) LEDs
(no combination colours possible, merely different brightness
between red, green and blue chains)
LEDM-2/RT + LEDM-2/GN + LEDM-2/BL
LEDS-5/RT + LEDS-5/GN + LEDS-5/BL
LEDS-5MP/RT + LEDS-5MP/GN + LEDS-5MP/BL
LEDS-5WP/RT + LEDS-5WP/GN + LEDS-5WP/BL
LEDS-96WP/RT + LEDS-96WP/GN + LEDS-96WP/BL
Chains with white (WS) and warm white (WWS) LEDs
(different brightness between three chains possible)
LEDL-9/WS
LEDL-9/WWS
LEDM-2/WS
LEDM-2/WWS
LEDS-5/WS
LEDS-5/WWS
LEDS-5MP/WS
LEDS-5MP/WWS
LEDS-5WP/WS
LEDS-5WP/WWS
LEDS-96WP/WS
LEDS-96WP/WWS
.
