Installation and Operating Instructions
CHAPTER 4
OPERATION
NOTE
Pressure sensor AIR1-CAP
4.0 Operation
Status LED
The status LED lights up in red for a short time when the unit is activated and the internal
power circuit is operational. If the LED is lit up during normal operation, a fault has occurred.
If the LED flashes yellow, the zero adjustment has been carried out incorrectly. In these ca-
ses, the pressure sensor will use the currently correct calibration.

Pressure switch

Short button press: Reset pressure sensor
The yellow LED lights up while the reset is carried out.
3
