230 VOLT MACHINES Instruction for
connection to the power supply and the
electrical ground
.
CAUTION: This machine will operate
only on the AC frequency and electrical
voltage shown on the nameplate. Make sure
you have the correct frequency and voltage
before connecting the power cord to an
outlet.
This machine must be connected to the electrical
ground to protect the operator from electric
shock. The machine has a power cord with two
main conductors and one earthing conductor.
Connect the plug to the type of receptacle shown
in figure 4. The green and yellow conductor in the
cord is the ground wire. Never connect this wire
to any terminal other than the ground terminal.
WARNING: Always use this machine
with an AC three-conductor electrical
system connected to the electrical
ground. Replace any worn, cut, or
damaged cords. Replace any damaged
plugs, receptacles, or connector
bodies. Do not move the machine over
an electrical cord. Always lift the cord
over the machine.
EXTENSION CORDS
Use only an approved extension cord with two
main conductors and one earthing conductor.
The machine has a power cord with wire size 1.5
2
mm
.
WARNING: If you use an extension
cord, use an extension cord with minimum
2
wire size 1.5mm
. Do not use an extension
cord longer than 15 meters. Do not join two
extension cords.
WARNING: Do not cut, remove, or
break the ground terminal. Do not try to fit a
three- terminal plug into a receptacle or
connector body that does not fit the plug.
If the receptacle or connector body does not
fit the plug, see your Authorized person to
make the connection.
Page -8 -
Schuko Plug
(German, Austria, The Netherlands,
Sweden,Norway, Finland, Portugal and
Spain)
CLARKE TECHNOLOGY Operator's Manual - C2K Series 230V Schuko
Pin Earthing Contact
(France and Belguim)
Side Earthing Contact
Figure 4
