9.1 Pelvic harness
For side adjustment, open the Camlocks and
either pull the straps to tighten or feed the
straps through to loosen, depending on fit
required (a). To adjust in the centre pull the D
Ring from the velcro and feed strap through
buckle on either strap to loosen the belt or
pull D rings away from the buckle to tighten
the belt (b).
Ensure strap is fed through the triglide as
a safety precaution in case the camlock is
opened accidently.
A
B
9.2 Hip laterals
To adjust the width of the hip laterals loosen
the knob (a) adjust to the required width and
retighten.
To adjust the depth, loosen the two allen
bolts (b) with the multi tool provided, adjust
to the required depth and retighten the allen
bolts.
The angle of the hip laterals can be adjusted
by loosening allen bolt (c), adjusting to the
required angle and retightening the bolt.
B
A
C
