CSS150 Product HANDBOOK
Input Parameters:
Standard
Nominal input voltage
Input voltage range
Input frequency range
Maximum input current
Input Connections: Input connector 3 pin header 09-65-2038 (center pin removed) 5A/250V MAX, mates
with Molex Housing 09-50-3031
Output Parameters:
Output channel
Vout (V)
CSS150-12
CSS150-15
CSS150-24
CSS150-36
CSS150-48
Output Connections: Output connector (CN3) is a 6 pin header 09-65-2068, mates with Molex Housing 09-
50-3061
Remote On/Off (CN2) mates with Molex Housing 481520210
Adjusting output voltage beyond the stated range may cause overvoltage protection (OVP) to operate,
whereby the output will latch off. To reset for normal operation simply adjust the potentiometer to reduce the
output voltage to within its range and cycle the input off then on.
All outputs are SELV except under the following circumstance: Outputs connected in series are non-SELV if
the total output voltage exceeds 60Vdc
If the total voltage of outputs connected in series exceed the 60Vdc SELV limit then all outputs must be
considered non-SELV.
Non-SELV outputs are hazardous and must not be made user accessible. Consideration must be given to
service engineers making inadvertent contact with the output terminals in the end equipmentNote:
Non-SELV outputs are hazardous and must not be made user accessible. They must be guarded or a
deflector fitted during installation to avoid a service engineer making inadvertent contact with the output
terminals, or dropping a tool onto them.
All outputs have operational spacings to earth, and due consideration must be given to this in the end product
design.
Safety Approvals:
IEC/EN/60601-1 CB Report and Certificate.
UL/CSA 60601-1 - UL + C -UL approval
nd
IEC / EN60950-1(2
Edition)
CE mark.
CE marking when applied to any CSS150-xx product, indicates compliance with the Low Voltage Directive
(2006/95/EC) in that it complies with EN60950-1, 2
60601-1
100-240VAC
90-264VAC
47-63Hz
1.7A
Convection
Output
Maximum
current (A)
power (W)
12
8.3
15
6.7
24
4.2
36
2.8
48
2.1
Page 14 of 16
60950-1
100-240VAC
90-264VAC
47-63Hz
1.7A
Forced Air
Output
current (A)
100
12.5
100
10
100
6.3
100
4.2
100
3.1
nd
Edition
Maximum
power (W)
150
150
150
150
150
th
72612 issue 4, 25
September 2015
