5. Base Mounting Outline Drawing
Heater
Housing
Dennard 515
Dennard 516
Optional wiper
built into base
232 (Dennard 515 housing)
260 (Dennard 516 housing)
288 (Dennard 517 housing)
Dennard 515, 516, 517 Installation Manual
9/9/09 4:38 pm Page 3
Terminal block
Z-rail
25
View on arrow 'A'
Arrow
Camera platform (Dennard 517)
'A"
Platform (Dennard 515 & 516)
2 x M6 holes on 101.6P.C.D
(Dennard 515 housing)
4 x M6 holes on 101.6P.C.D
(Dennard 516 & 517 housing)
Terminal block
Camera
platform
Earth point
3 x M20 Cable gland
Anti-vandal option
(Key Lock)
Optional internal fan
Page. 3
