USB Power Source
Source d'alimentation USB
Fuente de alimentación USB
IF YOU HAVE QUESTIONS OR COMMENTS, CONTACT US.
POUR TOUTE QUESTION OU TOUT COMMENTAIRE, NOUS CONTACTER.
SI TIENE DUDAS O COMENTARIOS, CONTÁCTENOS.
1–888–331–4569 WWW.CRAFTSMAN.COM
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in property damage.
USB Power Source Safety Warnings

WARNING: This manual contains important safety and operating instructions for this charging device. Before using the
charging device, read this manual and all labels on the power source, battery pack, charger and product(s) using the
power source.
Before using the USB power source, read all instructions and cautionary markings on the USB power source, battery pack
and product using the USB power source.
Shock hazard. Do not allow any liquid to get inside the USB power source. Electric shock may result.
Burn hazard. To reduce the risk of injury, use only 20V Max* lithium ion battery packs with the USB power source. Do not
attempt to use it on any other battery packs. Other types of batteries may overheat and burst resulting in personal injury and
property damage.
Do not charge appliance during use.
Do not use a worn USB cable.
Do not use the USB power source with installed battery pack to charge another battery pack.
Always use right USB cable. Do not use USB cable with current rating below 1.5 Amps. For fast charging, always use fast
charge cable with current rating higher than 2.0 Amps.
This USB power source is not intended for any uses other than supplying power/charging small USB electronics.
Any other uses may result in risk of fire, electric shock or electrocution.
Do not expose the USB power source to rain or snow.
When operating the USB power source outdoors, always provide a dry location.
Do not operate the USB power source if it has received a sharp blow, been dropped or otherwise damaged in any
way. Take it to an authorized service center.
Do not disassemble the USB power source, there are no user serviceable parts.
The label on your tool may include the following symbols. The symbols and their definitions are as follows:
V ......................... volts
Hz ....................... hertz
min ..................... minutes
or DC ...... direct current
...................... Class I Construction (grounded)
.../min .............. per minute
BPM .................... beats per minute
IPM ..................... impacts per minute
RPM .................... revolutions per minute
sfpm ................... surface feet per minute
SPM .................... strokes per minute
OPM .................... oscillations per minute
A ......................... amperes
W ........................ watts
BATTERIES AND CHARGERS
The battery pack is not fully charged out of the carton. Before using the battery pack and charger, read the safety
instructions below and then follow charging procedures outlined. When ordering replacement battery packs, be sure to
include the catalog number and voltage.
READ ALL INSTRUCTIONS
Important Safety Instructions for All Battery Packs

WARNING: Read all safety warnings, instructions, and cautionary markings for the battery pack, charger
and product. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious
injury.
• Do not charge or use the battery pack in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Inserting or removing the battery pack from the charger may ignite the dust or fumes.
• When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws,
or other small metal objects, that can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
• NEVER force the battery pack into the charger. DO NOT modify the battery pack in any way to fit into a non-
compatible charger as battery pack may rupture causing serious personal injury. Consult the chart at the end of this
manual for compatibility of batteries and chargers.
Charge the battery packs only in CRAFTSMAN chargers.
• DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in locations where the temperature may reach or exceed 104 °F
(40 °C) (such as outside sheds or metal buildings in summer). For best life store battery packs in a cool, dry location.
NOTE: Do not store the battery packs in a tool with the trigger switch locked on. Never tape the trigger switch in
the ON position.
Do not expose battery pack or tool/appliance to fire or excessive temperature. Exposure to fire or temperature above
265 °F (130 °C) may cause explosion.
• Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when lithium-ion battery packs are burned.
• If battery contents come into contact with the skin, immediately wash area with mild soap and water. If battery
liquid gets into the eye, rinse water over the open eye for 15 minutes or until irritation ceases. If medical attention is needed,
the battery electrolyte is composed of a mixture of liquid organic carbonates and lithium salts.
• Contents of opened battery cells may cause respiratory irritation. Provide fresh air. If symptoms persist, seek
medical attention.

WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or flame.

WARNING: Fire hazard. Never attempt to open the battery pack for any reason. If the battery pack case is cracked or
damaged, do not insert into the charger. Do not crush, drop or damage the battery pack. Do not use a battery pack or
charger that has received a sharp blow, been dropped, run over or damaged in any way (e.g., pierced with a nail, hit
with a hammer, stepped on). Damaged battery packs should be returned to the service center for recycling.
Storage Recommendations
1. The best storage place is one that is cool and dry, away from direct sunlight and excess heat or cold.
2. For long storage, it is recommended to store a fully charged battery pack in a cool dry place out of the charger for
optimal results.
NOTE: Battery packs should not be stored completely depleted of charge. The battery pack will need to be recharged before
use.
Battery Pack Cleaning Instructions
Dirt and grease may be removed from the exterior of the battery using a cloth or soft non-metallic brush. Do not use water
or any cleaning solutions.
Fuel Gauge Battery Packs
CRAFTSMAN battery packs include a fuel gauge which consists of three LED lights that indicate the level of charge
remaining in the battery pack.
The fuel gauge is an indication of approximate levels of charge remaining in the battery pack according to the
following indicators:
To actuate the fuel gauge, press and hold the fuel gauge button. A combination of the three LED lights will illuminate
designating the level of charge left. When the level of charge in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to be recharged.
NOTE: The fuel gauge is only an indication of the charge left on the battery pack. It does not indicate tool functionality and
is subject to variation based on product components, temperature and end-user application.
For more information regarding fuel gauge battery packs, please contact CRAFTSMAN at 1-888-331-4569 or visit our
website www.craftsman.com
Transportation

WARNING: Fire hazard. Do not store or carry the battery pack so that metal objects can contact exposed
battery terminals. For example, do not place the battery pack in aprons, pockets, tool boxes, product kit boxes,
drawers, etc., with loose nails, screws, keys, etc. Transporting batteries can possibly cause fires if the battery
terminals inadvertently come in contact with conductive materials such as keys, coins, hand tools and
the like. The US Department of Transportation Hazardous Material Regulations (HMR) actually prohibit transporting
batteries in commerce or on airplanes in carry-on baggage UNLESS they are properly protected from short circuits.
So when transporting individual battery packs, make sure that the battery terminals are protected and well insulated
INSTRUCTION MANUAL | GUIDE D'UTILISATION | MANUAL DE INSTRUCTIONES
CMCB002
or AC ........... alternating current
or AC/DC .... alternating or direct current
...................... Class II Construction (double insulated)
n o ....................... no load speed
n ......................... rated speed
...................... earthing terminal
..................... safety alert symbol
..................... visible radiation
..................... avoid staring at light
..................... wear respiratory protection
..................... wear eye protection
..................... wear hearing protection
..................... read all documentation
IPXX .................... IP symbol
75–100% charged
51–74% charged
< 50% charged
Pack needs to be charged
from materials that could contact them and cause a short circuit. NOTE: Li-ion batteries should not be put in
checked baggage.
The RBRC® Seal
The RBRC® (Rechargeable Battery Recycling Corporation) Seal on the nickel cadmium, nickel metal hydride
or lithium-ion batteries (or battery packs) indicates that the costs to recycle these batteries (or battery
packs) at the end of their useful life have already been paid by CRAFTSMAN. In some areas, it is illegal to
place spent nickel cadmium, nickel metal hydride or lithium-ion batteries in the trash or municipal solid waste stream and
the Call 2 Recycle® program provides an environmentally conscious alternative.
Call 2 Recycle, Inc., in cooperation with CRAFTSMAN and other battery users, has established the program in the United
States and Canada to facilitate the collection of spent nickel cadmium, nickel metal hydride or lithium-ion batteries. Help
protect our environment and conserve natural resources by returning the spent nickel cadmium, nickel metal hydride or
lithium-ion batteries to an authorized CRAFTSMAN service center or to your local retailer for recycling. You may also contact
your local recycling center for information on where to drop off the spent battery. RBRC® is a registered trademark of Call 2
Recycle, Inc.
Important Safety Instructions for All Battery Chargers

WARNING: Read all safety warnings, instructions, and cautionary markings for the battery pack, charger
and product. Failure to follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
DO NOT attempt to charge the battery pack with any chargers other than a CRAFTSMAN charger. CRAFTSMAN
chargers and battery packs are specifically designed to work together.
These chargers are not intended for any uses other than charging CRAFTSMAN rechargeable batteries. Any other
uses may result in risk of fire, electric shock or electrocution.
Do not expose the charger to rain or snow.
Pull by the plug rather than the cord when disconnecting the charger. This will reduce the risk of damage to the
electric plug and cord.
Make sure that the cord is located so that it will not be stepped on, tripped over or otherwise subjected to
damage or stress.
Do not use an extension cord unless it is absolutely necessary. Use of improper extension cord could result in risk of
fire, electric shock or electrocution.
When operating a charger outdoors, always provide a dry location and use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
An extension cord must have adequate wire size (AWG or American Wire Gauge) for safety. The smaller the gauge
number of the wire, the greater the capacity of the cable, that is, 16 gauge has more capacity than 18 gauge. An undersized
cord will cause a drop in line voltage resulting in loss of power and overheating. When using more than one extension to
make up the total length, be sure each individual extension contains at least the minimum wire size. The following table
shows the correct size to use depending on cord length and nameplate ampere rating. If in doubt, use the next heavier
gauge. The lower the gauge number, the heavier the cord.
Minimum Gauge for Cord Sets
Volts
120V
240V
Ampere Rating
More
Not
Than
More
Than
0
6
6
10
10
12
12
16
Do not place any object on top of the charger or place the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat. Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom of the housing.
Do not operate the charger with a damaged cord or plug–have them replaced immediately.
Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Take
it to an authorized service center.
Do not disassemble the charger; take it to an authorized service center when service or repair is required.
Incorrect reassembly may result in a risk of electric shock, electrocution or fire.
Disconnect the charger from the outlet before attempting any cleaning. This will reduce the risk of electric shock.
Removing the battery pack will not reduce this risk.
NEVER attempt to connect 2 chargers together.
The charger is designed to operate on standard 120V household electrical power. Do not attempt to use it on
any other voltage. This does not apply to the vehicular charger.

WARNING: Shock hazard. Do not allow any liquid to get inside the charger. Electric shock may result.

WARNING: Burn hazard. Do not submerge the battery pack in any liquid or allow any liquid to enter the battery pack.
Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, return
to a service center for recycling.

CAUTION: Burn hazard. To reduce the risk of injury, charge only CRAFTSMAN rechargeable battery packs. Other types of
batteries may overheat and burst resulting in personal injury and property damage.

CAUTION: Under certain conditions, with the charger plugged into the power supply, the charger can be shorted by
foreign material. Foreign materials of a conductive nature, such as, but not limited to, grinding dust, metal chips, steel
wool, aluminum foil or any buildup of metallic particles should be kept away from the charger cavities. Always unplug
the charger from the power supply when there is no battery pack in the cavity. Unplug the charger before attempting
to clean.
Charging a Battery
NOTE: To ensure maximum performance and life of lithium-ion battery packs, charge the battery pack fully before first use.
1. Plug the charger into an appropriate outlet before inserting battery pack.
2. Connect the charger and battery pack, making sure the battery is fully seated. The (charging) light will blink
continuously indicating that the charging process has started.
3. The completion of charge will be indicated by the light remaining ON continuously. The battery pack is fully charged
and may be removed and used at this time or left in the charger.
NOTE: To remove the battery pack, some chargers require the battery pack release button to be pressed.
Indicators
Charging
Fully Charged
Hot/Cold Pack Delay
A charger will not charge a faulty battery pack. The charger refusing to light could indicate a problem with the charger.
NOTE: If the charger refuses to light, take the charger and battery pack to be tested at an authorized service center.
Leaving the Battery Pack In the Charger
The charger and battery pack can be left connected with the charge indicator showing pack charged.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too cold, it automatically starts a Hot/Cold Pack Delay,
suspending charging until the battery pack has reached an appropriate temperature. The charger then automatically
switches to the pack charging mode. This feature ensures maximum battery pack life.
A cold battery pack may charge at a slower rate than a warm battery pack.
Important Charging Notes
1. Longest life and best performance can be obtained if the battery pack is charged when the air temperature is between
65 °F – 75 °F (18 ° C– 24 °C). DO NOT charge when the battery pack is below +40 °F (+4.5 °C), or above +104 °F (+40 °C).
This is important and will prevent serious damage to the battery pack.
2. The charger and battery pack may become warm to the touch while charging. This is a normal condition, and does not
indicate a problem. To facilitate the cooling of the battery pack after use, avoid placing the charger or battery pack in a
warm environment such as in a metal shed or an uninsulated trailer.
3. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp or other appliance;
b. Check to see if receptacle is connected to a light switch which turns power off when you turn out
the lights;
c. Move the charger and battery pack to a location where the surrounding air temperature is approximately 65 °F – 75 °F
(18 °C – 24 °C);
d. If charging problems persist, take the tool, battery pack and charger to your local service center.
4. The battery pack should be recharged when it fails to produce sufficient power on jobs which were easily done
previously. DO NOT CONTINUE to use under these conditions. Follow the charging procedure. You may also charge a
partially used pack whenever you desire with no adverse effect on the battery pack.
5. Foreign materials of a conductive nature such as, but not limited to, grinding dust, metal chips, steel wool, aluminum
foil, or any buildup of metallic particles should be kept away from charger cavities. Always unplug the charger from the
power supply when there is no battery pack in the cavity. Unplug the charger before attempting to clean.
6. Do not freeze or immerse the charger in water or any other liquid.
Charger Cleaning Instructions

WARNING: Shock hazard. Disconnect the charger from the AC outlet before cleaning. Dirt and grease may be removed
from the exterior of the charger using a cloth or soft non-metallic brush. Do not use water or any cleaning solutions.
Wall Mounting
These chargers are designed to be wall mountable or to sit upright on a table or work surface.  If wall mounting, locate the
charger within reach of an electrical outlet, and away from a corner or other obstructions which may impede air flow. Use
the back of the charger as a template for the location of the mounting screws on the wall. Mount the charger securely using
drywall screws (purchased separately) at least 1" (25.4  mm) long, with a screw head diameter of 0.28–0.35" (7–9 mm),
screwed into wood to an optimal depth leaving approximately 7/32" (5.5 mm) of the screw exposed. Align the slots on the
back of the charger with the exposed screws and fully engage them in the slots.
Versatrack™
CRAFTSMAN chargers can be mounted to the wall using CRAFTSMAN Versatrack™ Trackwall. Hooks and accessories are sold
separately. Please refer to the Versatrack™ Trackwall accessory sheet for further information.
Fig. A
1
INTRODUCTION
The USB power source is equipped with one USB Type A output port and is designed to charge or supply power to USB
compatible appliances with the use of CRAFTSMAN 20V Max* lithium ion battery packs. Consult the chart at the end of this
manual for compatibility of chargers and battery packs.
USB Charging Ports (Fig. A)
The USB power source
is equipped with one USB Type A output port
3
Total Length of Cord in Feet
(meters)
25 (7.6)
50 (15.2) 100 (30.5) 150 (45.7)
50 (15.2) 100 (30.5) 200 (61.0) 300 (91.4)
American Wire Gauge
18
16
16
14
18
16
14
12
16
16
14
12
14
12
Not Recommended
1
USB Type A output port
2
2
Belt Clip
USB power source
3
Battery pack
4
Fig. B
3
4
3
. The USB power source delivers 2 amps
1

Publicité

loading

Sommaire des Matières pour Craftsman CMCB002

  • Page 1 (or battery packs) indicates that the costs to recycle these batteries (or battery packs) at the end of their useful life have already been paid by CRAFTSMAN. In some areas, it is illegal to place spent nickel cadmium, nickel metal hydride or lithium-ion batteries in the trash or municipal solid waste stream and the Call 2 Recycle®...
  • Page 2 CMCB202, CMCB204 Le sceau SRPRC NOTE: Battery warranty voided if the battery pack is tampered with in any way. CRAFTSMAN is not responsible for any injury caused by tampering and may prosecute warranty fraud to the fullest extent permitted by law.
  • Page 3 El sello RBRC® (Rechargeable Battery Recycling Corporation) en las baterías (ounidades de batería) REMARQUE : la garantie de se produit sera annulée si le bloc-piles a été altéré de quelque façon que ce soit. CRAFTSMAN de níquel cadmio, níquel e hidruro metálico o de iones de litio indica que el costo de reciclaje de ne peut être tenu responsable de tout dommage corporel causé...
  • Page 4 CRAFTSMAN BATTERY AND CHARGER SYSTEMS energía a dispositivos compatibles con USB con el uso de paquetes de batería de ion de litio 20 V Máx de CRAFTSMAN. Consulte la tabla al final de este manual respecto a compatibilidad de cargadores y paquetes de batería.
