Layout - Samlex Power SEC-1215UL Manuel Du Propriétaire

SECTION 2 |
Fig. 2.1: Layout - SEC-1215UL
4 | SAMLEX AMERICA INC.

Layout

Automatic
Battery
Charger
3
LEGEND:
1 - Ammeter
2 - Red LED for ON status
3 - AC input power cord
1
2
12V - 15A Model
SEC-1215UL
5 6
- + + +
4 - DIP Switches S1, S2
5 - Common Negative
Output Terminal
6, 7 & 8 - Isolated Positive
4
7 8
Bank Terminals
