Function
instruction
NOTE
If too many bottles/cans are put in at
once or the door has not been
closed tightly, the unit will display the
"HI" signal at the diapaly panel.This
is normal please wait for a while
after you close the door and the
"HI" will disappear.
It is normal that the cabinet
shows "HI" or "LO" between times,
If it occurs frequently or lasts for a
long time, you can restart the unit by
unplugging it. If the problem
occurs once again after restart,
please contact the customer
service.
Wine
Storage
The *maximum capacity of
the DOBC7070SSST is 27
(750ml) wine bottles and
60(350ml) beverage cans.
*When stocked as per
instructions
Operating Instructions
• • Temperature Memory Function Temperature Memory Function
In the event of a power interruption, beverage center can remember the
previous temperature settings, and when the power is restored the
cabinet temperature will go back to the same setting temperature as
before.
• • Door Close Reminding Alarm Function Door Close Reminding Alarm Function
When you forget to close the door or the door is not closed completly
the buzzer alarm will sound after 5 minutes. Please close the door
completely to advoid the loss of cold energy.
• • Temperature Alarm Function Temperature Alarm Function
If inner temperature is higher than 74
in the display panel, and the buzzer alarm will sound after one hour
continuously.It informs that the inner temperature is too high,please
check the reason. If inner temperature is lower than 34°F(1°C) the "LO"
is shown in display panel and the alarm will turn on.
In order to achive the
maximum storage capacity
of 27 bottles and 60 beverage
cans.
1) Right
It will be necessary to
position the bottles alternately
on the upper six shelves,as
shown in Fig A. This will allow
for the storage of four(4)
750ml bottles per rack in each
of the top six shelves,and
three(3) bottles on the bottom
shelf for a total storage capacity
of 27 wine bottles.
2) Left
It will be necessary to
position the bottles alternately
on the upper three shelves,as
shown in Fig B. This will allow
for the storage of eighteen(18)
350ml cans per rack in each
of the top three shelves,and
six (6) cans on the bottom
shelf for a total storage capacity
of 60 beverage cans.
7
°
F(23°C), The "HI" is shown
Fig A
Fig B
