ASSEMBLY

UNPACKING
This product requires assembly.
 Carefully remove the tool and any accessories from the
box. All items listed in the Includes section must be
included at the time of purchase.
WARNING:
Items in this Assembly section are not assembled
to the product by the manufacturer and require
customer installation. Use of a product that may
have been improperly assembled could result in
serious personal injury.
 If any parts are damaged or missing, please call
1-866-539-1710 for assistance.

OPERATION

WARNING:
Do not allow familiarity with this product to make
you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
WARNING:
Always remove battery pack from the tool when
you are assembling parts, making adjustments,
cleaning, or when not in use. Removing battery
pack will prevent accidental starting that could
cause serious personal injury.
WARNING:
Always wear eye protection with side shields
marked to comply with ANSI Z87.1. Failure to do
so could result in objects being thrown into your
eyes and other possible serious injuries.
WARNING:
Do not use any attachments or accessories not
recommended by the manufacturer of this product.
The use of attachments or accessories not recom-
mended can result in serious personal injury.
APPLICATIONS
You may use this product for the purposes listed below:
 Drilling in all types of wood products (lumber, plywood,
paneling, composition board, and hard board), ceramics,
plastics, fiberglass, laminates, and metals; driving screws
into wood and drywall with screwdriver bits
WARNING:
If any parts are damaged or missing do not oper-
ate this product until the parts are replaced. Use of
this product with damaged or missing parts could
result in serious personal injury.
WARNING:
Do not attempt to modify this product or create acces-
sories or attachments not recommended for use with
this product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
OVERLOAD PROTECTION
When the tool is forced or the motor is overloaded, the tool
will automatically shut off. To reset the tool, release the trigger
and resume operation. If the tool still does not resume opera-
tion, remove and reinsert the battery. Do not force the tool.
HIGH TEMPERATURE PROTECTION
Li-ion battery packs are equipped with a high temperature
protection feature that automatically deactivates the tool
when it is overheated. To resume operation, allow the tool
to cool and then squeeze the trigger.
INSTALLING/REMOVING BELT HOOK OR BIT
HOLDER
See Figure 1, page 10.
The belt hook and bit holder are interchangeable. They may
be installed on either side of the base.
 Align hole in belt hook or bit holder with hole in tool's
base.
 Install screw to secure belt hook or bit holder in place.
 To uninstall, remove screw and then belt hook or bit
holder.
VARIABLE SPEED SWITCH TRIGGER
See Figure 2, page 10.
The variable speed switch trigger delivers higher speed with
increased trigger pressure and lower speed with decreased
trigger pressure.
To turn the drill ON, depress the switch trigger. To turn it
OFF, release the switch trigger and allow the chuck to come
to a complete stop.
NOTE: A whistling or ringing noise coming from the switch
during use is a normal part of the switch function.
6 - English
