Operating Instructions
Balancer
040836-...x2,7
3

Adjusting the spring force

Do not set the spring force to zero.
To increase the tensile force, the spring housing is rotated in
the direction of the cable pull.
4

Notes on use

BAL0402-0003 D/E/F
www.conductix.com
Never jerk hard!
Only adjust the spring force when a load is attached.
The tensile force is decreased in increments by using the arm.
Blocking the brake to change
load:
Follow the bow-and-arrow
principle
Page 11 of 20
